Pagina 1/10
PRODUCT SPECIFICATION
evolution wireless G4
ew 100 G4-ME2/835-S | Combo Set
1/10
FEATURES
• Engineered for professional live sound:
Rugged all-in-one combo wireless system for singers,
presenters and moderators.
• Dynamic handheld microphone e 835, robust bodypack
transmitter and unobstrusive clip-on microphone ME
2-II (omni-directional) with high speech intelligibility for
daily use on stage
• True diversity half-rack receiver in a full-metal housing
with intuitive LCD display for full control
• Easy and flexible wireless synchronization between
transmitter and receiver via infrared
• Fast frequency allocation for up to 12 receivers via new
linking functionality
• Up to 20 compatible channels
• Up to 42 MHz bandwidth with 1680 selectable frequen-
cies, fully tunable in a stable UHF range
• Transmission Range: up to 100 meters / 300 feet
• High RF output power (up to 30 mW) depending on
country regulations
DELIVERY INCLUDES
• EM 100 G4
• SK 100 G4
• SKM 100-S G4
• MMD 835-1
• ME 2
• GA 3
• MZQ 1 microphone clamp
• power supply
• 4 AA batteries
• antennen
• RJ 10
• quick guide
• safety guide
• manufacturer declaration sheet
• frequency supplement sheet
Versatile wireless systems for those who sing, speak or play instruments with up to 42 MHz tuning bandwidth in a stable
UHF range and fast, simultaneous setup of up to 12 linked systems.
Dynamic handheld microphone e 835, robust bodypack transmitter and easy clip-on microphone ME 2-II (omni-directio-
nal) with high speech intelligibility for daily use on stage.
PRODUCT SPECIFICATION
evolution wireless G4
ew 100 G4-ME2/835-S | Combo Set
2/10
SPECIFICATIONS
EM 100 G4
RF characteristics
Modulation Wideband FM
Frequency ranges A1: 470 - 516 MHz
A: 516 - 558 MHz
AS: 520 - 558 MHz
G: 566 - 608 MHz
GB: 606 - 648 MHz
B: 626 - 668 MHz
C: 734 - 776 MHz
D: 780 - 822 MHz
E: 823 - 865 MHz
JB: 806 - 810 MHz
K+: 925 - 937.5 MHz
1G8: 1785 - 1800 MHz
Receiving frequencies Max. 1680 receiving
frequencies, adjustable in
25 kHz steps
20 frequency banks, each
with up to 12 factory-preset
channels, no intermodula-
tion
1 frequency bank with up to
12 programmable channels
Switching bandwidth up to 42 MHz
Nominal/peak deviation ±24 kHz / ±48 kHz
Receiver principle True diversity
Sensitivity (with HDX, peak
deviation)
< 2.5 μV for 52 dBA
eff S/N
Adjacent channel selection Typically ≥ 65 dB
Intermodulation attenua-
tion
Typically ≥ 65 dB
Blocking ≥ 70 dB
Squelch low: 5 dBμV
middle: 15 dBμV
high: 25 dBμV
Pilot tone squelch Can be switched off
Antenna inputs 2 BNC sockets
AF characteristics
Compander system Sennheiser HDX
EQ presets (switchable,
act on line and monitor
outputs)
Preset 1: Flat
Preset 2:
Low Cut (-3 dB at 180 Hz)
Preset 3:
Low Cut/High Boost
(-3 dB at 180 Hz,
+6 dB at 10 kHz)
Preset 4:
High Boost
(+6 dB at 10 kHz)
Signal-to-noise ratio (1 mV,
peak deviation)
≥ 110 dBA
Total harmonic distortion
(THD)
≤ 0.9 %
AF output voltage (at peak
deviation, 1 kHz AF)
6.3 mm jack socket
(unbalanced): +12 dBu
XLR socket
(balanced): +18 dBu
Setting range “AF Out”48 dB (3 dB steps)
Overall device
Temperature range -10 °C to +55 °C
Power supply 12 V DC
Current consumption 300 mA
Dimensions Approx. 190 x 212 x 43 mm
Weight Approx. 980 g
DC IN 12V/300mA
DC IN 12V/300mA
AF OUT
BAL/UNBAL
DATA
DATA
ANT II
ANT I
RF IN
RF IN
CONNECTIONS
PRODUCT SPECIFICATION
evolution wireless G4
ew 100 G4-ME2/835-S | Combo Set
3/10
SPECIFICATIONS
SK 100 G4
RF characteristics
Modulation Wideband FM
Frequency ranges A1: 470 - 516 MHz
A: 516 - 558 MHz
A10: 516 - 558 MHz
AS: 520 - 558 MHz
G: 566 - 608 MHz
GB: 606 - 648 MHz
B: 626 - 668 MHz
B10: 626 - 668 MHz
C: 734 - 776 MHz
D: 780 - 822 MHzt
JB: 806 - 810 MHz
E: 823 - 865 MHz
K+: 925 - 937,5 MHz
1G8: 1785 - 1800 MHz
Transmission frequencies Max. 1680 receiving
frequencies, adjustable in
25 kHz steps
20 frequency banks, each
with up to 12 factory-preset
channels, no intermodula-
tion
1 frequency bank with up to
12 programmable channels
Switching bandwidth up to 42 MHz
Nominal/peak deviation ±24 kHz / ±48 kHz
Frequency stability ≤ ±15 ppm
RF output power at 50 ΩMax. 30 mW
Pilot tone squelch Can be switched off
AF characteristics
Compander system Sennheiser HDX
AF frequency response Mic: 80 – 18,000 Hz
Line: 25 – 18,000 Hz
Signal-to-noise ratio (1 mV,
peak deviation)
≥ 110 dBA
Total harmonic distortion
(THD)
≤ 0.9 %
Max. microphone/line
input voltage
3 V
eff
Microphone/line input
impedance
40 kΩ, unbalanced / 1 MΩ
Input capacitance Switchable
Setting range for input
sensitivity
60 dB,
adjustable in 3 dB steps
Overall device
Temperature range -10 °C to +55 °C
Power supply 2 AA batteries, 1.5 V or
BA 2015 accupack
Nominal voltage 3 V battery /
2.4 V rechargeable battery
Current consumption at nominal voltage:
typ. 180 mA
with transmitter switched
off: ≤ 25 μA
Operating time Typically 8 h
Dimensions Approx. 82 x 64 x 24 mm
Weight (incl. batteries) approx. 160 g
SPECIFICATIONS
ME 2
Transducer principle pre-polarized condensor
microphone
Pick-up pattern omni-directional
Sensitivity (free field, no
load) (1 kHz)
20 mV/Pa
Max. SPL at 1 kHz 130 dB
Frequency response 50 to 18,000 Hz
Equivalent noise level
A-weighted (DIN IEC 651)
36 dB
Connector 3.5 mm jack
Cable length approx. 1.60 m
Supply voltage 7.5 V
