LED WORK LIGHT INSTRUCTION

1. Light Structure and Features

a. This light is unique, novel. Its back cover and front

cover can be separated, easy to install and

replace.

b. The shell is ADS12 Casting aluminum with

heatsink. Its surface is electrostatic sprayed and

solidified in constant temperature so that its

adhesion force is strong.

c. It has good waterproof, dustproof, and shock-proof.

2. Application

Applying to automobiles, trucks, off-road vehicles,

excavators, agricultural machinery, marine machinery, etc.

3. Product Specification

a. Model: TP917

b. Size: 175*86*202mm

c. Power: 51W

d. Voltage: 10-30V

e. Luminous flux: 3740lm

f. Beam types: Flood

g. LED Lead Quantity: 17pcs*3W

h. Color temperature: 6000K

i. Waterproof: IP67

j. Material: ADS12 Casting aluminum with heatsink

K. Mounting Bracket: Aluminum

L. Life Time:30000 hours

m. Weight: 2.6kg

4. Installing Requirement & Maintenance

a. First of all, all the component and accessories

should be organized.

b. Before installation, test the light to make sure it can

work properly. (Red line is positive, black line is

negative.)

c. First, install the hex nuts on the bolts, and twist

the spring meson.

d. Make the bolts go through the mounting holes, and

set into the spring meson, and then tighten the

hex nut.

e. Connect the power line to the corresponding power

connector.

f. Finally, make sure the light is installed steadily, and

then start the power.

5. Notes

a. It is unqualified if there was breakage in the light

shell or glass/plastic cup; the light should not be

used.

b. When installing, the power should be cut off to

avoid injury to body

.
