OPERATING INSTRUCTIONS
Pump Control
with device switch-off
SHT 217 | SHT 218
SHT 227 | SHT 228
Item number
300217 | 300218 | 300227 | 300219
• Intermediate plug housing with device switch-on
with fork water sensor or mini fl oat switch
Overrun time adjustable 0-100 seconds
up to 2300W / 3500 VA switching capacity
2
Thank you very much for your trust!
In order to guarantee optimum function and performance of the product
at all times and to ensure your personal safety, we would like to ask you to
read these operating instructions thoroughly before installation and initial
start-up and, above all, to follow the safety instructions! The operating in-
structions are an integral part of this product. Please keep them for future
reference!
Scope of delivery
1 SHT 217 | SHT 218 pump control unit with SHT 5006 fork sensor or
1 pump control SHT 227 | SHT 228 with mini fl oat switch
Installation material (1 screw, 1 dowel), 1 instruction manual
Safety instructions
• Read the operating instructions carefully before installing or operating
the appliance.
• Packaging material is not a child‘s toy. Keep them away from children.
• Do not open the appliance as it does not contain any serviceable parts.
Ambient conditions
The standards used to assess the product specify limit values for use in
residential, commercial and small business environments, which means
that the product is intended for use in these operating environments:
• Residential buildings/living spaces such as houses, fl ats, rooms, etc.
Sales areas such as shops, hypermarkets, etc.
• Small business premises such as workshops, service centres, etc.
• All locations are characterised by the fact that they are connected to the
public low-voltage network
Intended use
The SHT 217 | 218 | 227 | 228 pump control units are devices for detecting
changes in water level and monitoring pump sumps. As soon as the sen-
sor | mini fl oat switch comes into contact with water, a connected pump
is switched on. The overrun time of the pump can be set from 0 to 100
seconds using the setting wheel on the device. Depending on the device, a
visual warning signal appears or an acoustic warning also sounds.
3
Sensor
Pumpe
Wassermelder
SHT 217
Pumpensumpf
Technical data SHT 217 | SHT 218 and SHT 227 | SHT 228
Operating voltage: 230 V~ (+/-10%) / 50-60 Hz
Power consumption: approx. 3 W
Switching capacity: 3500 VA (2300 W) / 16 A (10 A)
Operating range: -15 °C / +40 °C
Protection class: IP 20
Sound pressure buzzer: 80 dB (distance 10 cm)
Cable: 2x0.14mm² - white - Ø 3.2 mm
Cable length: 2.8 m (SHT 216) | 2.5 m (SHT 226)
Dimensions (HxWxD): 121x57x38 mm
