www.sauermanngroup.com 1 /05 9 Page 06 /201
Si-27
Sauermann® part #:
SI27CE01UN23
PISTON PUMP
Versatile technology
The Si- - . 27 is suitable for air conditioning units up to 20 kW
The piston technology is specifically designed for removing
condensates from air conditioning systems.
The Si- 27 is fully reliable in any kind of environment and its sound
l evel remains quiet regardless of the condensate volume.
BENEFITS
● Patented technology
High performance: o . nly one pump is needed for air conditioning units up to 20 kW
Highly resistant to pollution created by general environments and capable of discharging small
particles.
- Proven reliability
● Silent
- ). Low operating sound levels: quiet in operation (20 dBA independently tested
- -The size of the air conditioning unit and volume of condensates to be removed does not
affect the operational sound level of the pump.
● Easy to install
- Mounting bracket: allows the pump to be wall mounted or hung from ceilings and
pipework.
- Plug-in power cable makes maintenance and replacement hassle free.
- Safety switch
● Energy saving
Improved performance and high flow rate reduce operation time and energy consumption.
KIT CONTENTS
- Piston pump
- Mounting bracket
- -1.5 m plug in power cable
- 1.5m clear PVC tube Ø int 6 mm
- 6 tie wrap
- Detection unit (SI2958, 1.5m cable)
- Detection unit installation kit:
§ rubber hose Øint.15 x L 35 mm,
§ vent tube Ø int 4 x L 75 mm,
§ mounting rail,
§ adhesive.
www.sauermanngroup.com 2 /05 9 Page 06 /201
APPLICATIONS
For use with any air-conditioning units, up
to 20 kW:
● Wall mounted
● Ceiling suspended
● Ducted
•
•
•
••
- Fan coils
TECHNICAL SPECIFICATION
Max. flow rate
20 l/h
Max. suction head
3 m
Max. discharge head
10 m (flow rate =4l/h)
Max pressure
14 m (flow rate =0l/h)
Sound level at 1m according to
EN ISO 3744 (Measured at LNE lab, pump
operating with water, out of application)
20 dBA
Mains supply
230V 50/60Hz 14W (SI27CE01UN23)
Insulation class
(double insulation)
Detection levels
ON: 16mm, OFF: 11mm,Safety: 19mm
Safety switch
NC 8 A re – sistive 250V
Thermal protection (overheating)
115°C (auto- reset)
Operating conditions
100% Continuous duty
Protection
IP20
Safety standards
CE / EAC
RoHS directive
Compliant
W EEE directive
Compliant
Packaging
0.48kg L135 x W135 x H90 mm–
Masterpack
20 pieces
ACTUAL FLOW RATES (l/h)
Total hose length
using Ø Int 6 mm, 1/4'' – (C)
Suction head (A)
Discharge head (B)
5 m
10 m
20 m
30 m
0 m
0 m
20
19
18
17
2 m
16
15
14
13,5
4 m
11,5
11
10,5
10
6 m
8,5
7,5
6,5
8 m
6
5
4
10 m
4
3,5
2,5
1 m
0 m
14
13
12
11
2 m
11
10
9
8
4 m
7,5
7
6
5
6 m
4,5
4
2 m
0 m
11
10
9
8
2 m
9
8
7
6
4 m
5,5
5
4,5
3 m
0 m
10,5
9
8
7
2 m
8
7
6
5
4 m
5
4
RECOMMENDED ACCESSORIES
Clear PVC hose Ø int. 6mm (1/4")
ACC00909 : 5 m
ACC00910 : 50 m
Self sealing- fittings for hose
Ø int. 6 mm (1/4")
CC00919
Drain Safe Devices for
hose 6 mm (1/4") Ø int.
ACC00922
Non contractual document. We reserve the right to modify the characteristics of our products without prior notice.
