List of Parts

1

Remote Control & Batteries (AAA x 2)

2

Power Cord

3

Cover-Bottom

4

Data Cable

5

Stand & Screw (M4xL16)

6

• Owner’s Instructions

• Safety Guide

7

Guide Stand (32inch model only)

8

Cover Neck (32inch model only)

9

Screws (32inch model only)

0

Stand (32inch model only)

To register this product please visit

www.samsung.com/register.

Quick Setup Guide

Installing the Stand

➣Preset:Place the Guide Stand and Cover Neck onto the stand and fasten it using

the screws. Applicable to 32 inch model only.

1.Attach your LCD TV to the stand.

➣Two or more people should carry the TV.

➣Make sure to distinguish between the front and back of the stand when

attaching it.

➣To make sure the TV is installed on the stand at a proper level, do not apply

excess downward pressure to the upper left of right sides of the TV.

2. Fasten two screws at position and then fasten two screws at position .12

➣Stand the product up and fasten the screws. If you fasten the screws with the

LCD TV placed down, it may lean to one side.

➣The stand is installed for models with the screen size of 37 inch and above.

Installing the Wall Mount Kit

Wall mount items (sold separately) allow you to mount

the TV on a wall. For detailed information on installing

the wall mount, see the instructions provided with the

Wall Mount items. Contact a technician for assistance

when installing the wall mounted bracket. Samsung

Electronics is not responsible for any damage to the

product or injury to yourself or others if you select to

install the TV on your own.

Do not install your Wall Mount Kit while your TV

is turned on. It may result in personal injury due to electric shock.

➣Remove the stand and cover the bottom hole with the cover.

➢ Make sure to distinguish between the front and back of each

component when assembling them.

➢ Make sure that at least two persons lift and move the LCD TV.

➢ Stand the product up and fasten the screws.

If you fasten the screws with the LCD TV placed down, it may lean

to one side.

Caution

Installing the LCD TV Stand (32inch model only)

1. Insert the Cover Neck into the groove of the stand. Assemble the LCD TV stand

by aligning the triangle figures indicated by the arrow marks.

2. Place the Guide Stand onto the stand which is assembled in step1 and fasten it

using the three screws.ⓐ

3.

Connect your LCD TV and the stand.

4.

Fasten two

ⓑ

screws at position

1

and then fasten two

ⓑ

screws at position

2

.

1

Front

Back

2

Front

Back

3

Position

2

Position

1

4

Viewing the Connection Panel

➣The product color and shape may vary depending on the model.

➣Whenever you connect an external device to your TV, make sure that power on the unit is turned off.

➣When connecting an external device, match the color of the connection terminal to the cable.

1VARIABLE AUDIO OUT

2

VOL-CTRL

3ANT IN

4HDMI IN 1(DVI), 2, 3

55V DC/2.5A

(12V DC/1.5A)

6PC/DVI AUDIO IN

7PC IN

8USB / CLONING

9DATA

0RJP

!COMPONENT IN / AV IN

@EXT

#HEADPHONE JACK

$HP-ID

93!8

@

746

Power Input

LE22D460C9H

LE22D463C8H

LE22D467C9H

93!8

@

74#

Power Input

LE22D460C9L

LE22D463C8L

HDMI IN3

4

8

14769

02!

@

3

Power Input

HDMI IN3

4

8

14769

0#!

@

3

HP-ID

$

Power Input

LE26D460C9H

LE26D463C8H

LE26D460C9L

LE26D463C8L

HDMI IN3

4

8

14769

02!

@

3

LA26D467C9H

HDMI IN3

4

8

14769

02!

@

3

Power Input

LE32D460C9H

LE32D463C8H

LE32D580K2H

LE37D580K2H

HDMI IN3

4

8

14769

02!

@

3

Power Input

LA32D467C9H

LA37D467C9H

LA40D467C9H

HDMI IN3

4

8

4

7

6915

ANT 2IN

(SATELLITE)

!

@

023

Power Input

LE32D467C9H

LE37D467C9H

LE40D467C9H

HDMI IN3

4

8

4

7

69

@

15

0!32

Power Input

LE26D467C9H

BN68-03592A-02

Power Input

1

5

2

3

67

9

0

8

4

[QSG]BN68-03592A-ENG.indd 12011-10-05 �� 10:56:09
