Air to Water Heat Pump
Installation manual
Outdoor Unit AE***CXEDEG / AE***CXEDGG
• Thank you for purchasing this Samsung Product.
• Before operating this unit, please read this installation manual carefully and retain it for future
reference.
ki]_TXYYXXhTWWptlozGyTZYGzwsp{Gv|{kvvyG䚐⣡㫴l|luUGGGX YWYZTWXTX_GGG㝘㤸G`a\XaZ[
ENGLISH-2
Contents
PREPARATION
Safety precautions ....................................................................................................... 3
Product specications ................................................................................................... 5
INSTALLATION
Outdoor unit specication ............................................................................................... 6
Main components ....................................................................................................... 7
Installing the unit ........................................................................................................ 8
Electrical connections ................................................................................................... 19
Connecting the cable ................................................................................................... 20
Refrigerant piping work ................................................................................................ 28
Checking correct grounding ............................................................................................ 41
Setting the option switch and function of the keys ...................................................................... 41
Pump down procedure ................................................................................................. 46
Completing the installation ............................................................................................. 48
Final checks and trial operation ......................................................................................... 49
OTHERS
Troubleshooting ........................................................................................................ 50
Error codes ............................................................................................................. 50
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other household waste at the end of their working
life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please
separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of
material resources.
Household users should contact either the retailer where they purchased this product, or their local government
oce, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product and its electronic accessories should not be mixed with other commercial wastes for disposal.
For information on Samsung’s environmental commitments and product-specic regulatory obligations, e.g. REACH,
visit: https://www.samsung.com/uk/sustainability/environment/environment-data/
