Air conditioner
Installation manual
AC***BX**C*
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this manual carefully and retain it for future reference.
ki]_TXXY^[hTWZptjhjG|GvhhluUGGGX YWYYTW_TYZGGG㝘㤸G_a[XaXZ
2
English
Contents
Safety Information 3
General information 3
Safety Information 3
Installing the unit 4
Power supply line, fuse or circuit breaker 4
Installation Procedure 5
Step 1 Choosing the installation location 5
Step 2 Checking and preparing accessories and tools 8
Step 3 Fixing the outdoor unit in place 8
Step 4 Connecting the power cables, communication cable, and controllers 9
Step 5 Optional: Extending the power cable 18
Step 6 Connecting the refrigerant pipe 20
Step 7 Optional: Cutting and flaring the pipes 21
Step 8 Connecting up and removing air in the circuit 22
Step 9 Performing the gas leak test 24
Step 10 Adding refrigerant (R-410A) 24
Step 11 Connecting the drain hose to the outdoor unit 26
Step 12 Insulating the refrigerant pipes 27
Step 13 Checking the earthing 27
Step 14 Performing final check and trial operation 28
Step 15. Auto check(Installation commissioning mode) 32
Extra procedures 33
Pumping down refrigerant 33
Relocating the indoor and outdoor units 33
Using the stop valve 34
Installing the wind baffle 35
Appendix 37
Troubleshooting 37
IMPORTANT – This product has been designed and manufactured to meet ENERGY STAR criteria for energy efficiency
when matched with appropriate coil components.
However, proper refrigerant charge and proper air flow are critical to achieve rated capacity and efficiency.
Installation of this product should follow the manufacturer’s refrigerant charging and air flow instructions.
Failure to confirm proper charge and airflow may reduce energy efficiency and shorten equipment life.
