Full-HD (3G/HD-SDI,HDMI) 2.16MP Mini-Broadcast POV

Camera with CS Mount Lens

·

2.16 Megapixel 1/2.8" Exmor R CMOS Sensor

·

CS Mount Type

Lens installed (interchangeable)

-CS-055D : 5.0 ~ 50mm (Focal Length), H(51˚ ~ 6.1˚)

-CS-2712D : 2.7 ~ 12mm (Focal Length), H(18.78˚~30.62˚)0

·

V-CVS/CVH(50/60) : 1920x1080p60/50/30/25,

1920x1080i60/50,1280x720p60/50/30/25fps

·

V-CVS/CVH

(59.94) : 1920x1080p59.94/29.97, 1920x1080i59.94,

1280x720p59.94/29.97fps

·

3G/HD-SDI (BNC) CABLE built into rear panel

·

Audio Mic Stereo (TRS) input embedding

·

OSD Menu Joystick, RS-422/485 connectable (PELCO/VISCA

)

Features

Dimensions

Specifications

Precautions

46.0

47.5

46.0

39.8

150

500

3G-SDI

RS-485/422

AUDIO

IR INPUT

VIDEO

POWER

TX-

RX+/TX+

RX-/TX-

TX+

SENSOR

Image Sensor

1/2.8” Exmor R CMOS (Approx. 2.16 mega)

Scanning System

16:9 Progressive

Sync. System

Internal

Effective Pixel

1945 (H) X 1097 (V) approx.. 2.13M pixels

Min. Illumination

Color : 0.1 lx (1/30 sec),B&W: 0.01 lx (1/30 sec)

Optics

Lens

CS-055D CS-2712D

5

.0 ~ 50mm (Focal Length), H(51˚ ~ 6.1˚

)

2

.7 ~ 12mm (Focal Length), H(108.78˚ ~ 30.62˚

)

Functions

EXPOSURE BRIGHTNESS / SHUTTER / SENS-UP / AGC

BACKLIGHT HLC/BLC/WDR

DAY&NIGHT AUTO / COLOR / B&W / EXTERN

WHITE BALANCE AUTO (3,000°K~8,000°K)/ AUTOext (1,900°K~11,000°K) / PRESET / MANUAL

Electronic Shutter NTSC: 1/30~1/30000, PAL: 1/25~1/30000, SENS-UP ( ~X64)

Functions

Privacy Mask, Image Mirror, 3DNR, GAMMA Control,

Lens Shading, Flickerless, Sharpness, Defog,

Intelligent Motion Detection

V

ideo outpu

t

SDI (BNC)

SMPTE 292M (1.485Gbps): 1080p@25/30, 1080i@50/60, 720p@50/60, 720p@25/30

SMPTE 424M (2.97Gbps) : 1080p@50/60

Audio

Input

MIC Input

Mic Level (1Vrms). 2.5V Mic bias

Audio On / Off

CONTROL

RS422/485

REMOTE CONTROL

2400~115200bps

PELCO, D/P, VISCA

General

O

peration Temperatur

e

0℃ ~ 50℃

Power Input

12VDC (7VDC to 15VDC)

Power consumption

Max 3.6W

Dimensions

47.5(W) x 46(H) x 39.8(D) mm (Without Lens)

Net Weight

Approx. 200g

focalSHOT UltraLatency

+82 2626 6425

Unit 905, 1126 Beoman-ro, Geumcheon-gu, Seoul, Korea 08595

[email protected]

www.salrayworks.com
