MX28

Mini-Mix VI

Owners Manual

MX28 INIIX VIMM

• Three stereo inputs - 2: 1/4" unbal per channel.

• Individual 1/4" Right and Left outputs

• Pan control for each channel

• Two Stereo Phone Outs; 1/4" and 1/8" (3.5mm)

The MX28 is the ideal mixer for anyone needing to mix up to

three stereo signals. Keyboards, stereo guitar eects, even

sources like CD players or cassette players can be mixed together

maintaining their true stereo separation.

SPECIFICATIONS

Input Impedance: 10K Ω

Output Impedance: 100 Ω

Max Gain: +27 dBV

Max Input Level: +30 dBV

Max Output Level: +13 dB

Frequency Response: 20Hz - 20kHz +/- 1 dBV

THD + Noise: <.005%

Power: 12 VDC 150 mA adapter (center negative)

Weight: 1.2 lbs. (.49 Kg)

Size: 4.25" x 1.75" x 4.5" (WxHxD)

Rolls Corporation

Salt Lake City, UT

10/18

1

23

OUTPUT

DC IN

12 - 16

VDC

MX28

STEREO

MINI-MIX VI

LEVEL

1

BAL

LEVEL

2

BAL

LEVEL

3

BAL

MASTER

LEVEL

HEADPHONE

LEVEL

MADE IN USA

www.rolls.com

R

LL

R

L

R

L

R

7588900280

65
