Functions Addedin Ver.1.80

Undo/Redo Function Added

This function lets you revert a phrase to how it was just before it was

edited.

*The messages “Can’t UNDO” or “Can’t REDO” are shown when undo/

redo can’t be performed.

Undoing the previous operation

(UNDO)

1.

Press the [EXIT] and MEASURE [<] buttons at the same time.

“UNDO” is shown in the display, and the sequencer returns to the

previous state.

For a step recording, this undoes the step that you just inputted or

erased.

For a real-time recording, this undoes the recorded step and motion

state.

*When you switch between tracks or clips, the undo content is erased.

*You can’t undo or redo while recording in real time.

*You can undo up to 10 times.

Reverting an Undo Operation

(REDO)

1.

Press the [EXIT] and MEASURE [>] buttons at the same time.

“REDO” is shown in the display, and the data reverts to how it was

before you did the undo operation.

Added Function for Continuously Assigning Sliced Samples

A sampling function has been added for continuously assigning sliced

samples.

In step 7 (loading into a track) of “Sampling to a tone or drum track”

(P.16), you can now press the [ENTER] button while holding down

the [NOTE] button to continuously assign sliced samples each time you

press the button.

Exciter, Phonograph and JD Multi Added to MFX

An Exciter eect has been added to the Filter category, a Phonograph

eect has been added to the Lo- category, and a JD Multi eect has

been added to the Combination category.

Exciter

This adds dynamics to the sound, by dynamically bringing up the high

end using a split-band compressor.

L out

Low

Mid

High

L in

Compressor

Compressor

Channel

Divider

R out

Low

Mid

High

R in

Compressor

Compressor

Channel

Divider

ParameterValueExplanation

Band2 Th-80.0–0.0 (dB)

Raises the midrange frequency levels when

they fall below the specied amount.

ParameterValueExplanation

Band2 Gain0–+24 (dB)

Sets how much to raise the levels when the

midrange volume is low.

Band3 Th-80.0–0.0 (dB)

Raises the high-end frequency levels when

they fall below the specied amount.

Band3 Gain0–+24 (dB)

Sets how much to raise the levels when the

high-end frequency volume is low.

Split1 F2000–5000 (Hz)

Frequency at which the low and midrange

frequencies are split

Split2 F3000–10000 (Hz)

Frequency at which the midrange and high-

end frequencies are split

Level0–127Output Level

Phonograph

Recreates the sound of an analog record being played on a record

player. This lets you simulate the unique noises produced when a

record is played, as well as the variations that occur when the record

spins.

Balance W

Balance D

Balance D

R outR out

L outL out

BalanceW

L inL in

PhonographPhonographPhonographPhonograph

R inR in

PhonographPhonographPhonographPhonograph

ParameterValueExplanation

Signal Dist0–127Sets the amount of distortion.

Freq Range0–127

Sets the frequency characteristics of the playback system.

Smaller values create the feeling of an older system with

narrow frequency bands.

Disc TypeLP, EP, SP

Sets the turntable rotation speed.

This has an eect on the scratch noise cycle.

Scratch NZ0–127Sets the volume of noise created by scratches in the record.

Dust NZ0–127Sets the volume of noise created by dust on the record.

Hiss NZ0–127Sets the volume of continuous hiss noise.

Total NZ0–127Sets the volume of noise overall.

Wow0–127Sets the amount of variation in record spin (long cycle).

Flutter0–127Sets the amount of variation in record spin (short cycle).

Random0–127Sets the amount of non-cyclical variation in record spin.

Total W/F0–127Sets the volume of variation in record spin overall.

Balance

D100: 0W

-D0: 100W

Sets the volume balance between the original sound (D)

and the eect sound (W).

Level0–127Sets the output volume.

© 2020 Roland Corporation

MC-707 Update
