1：Video screen preview box

2：Menu

Default is "Video", "Audio" is the sound

control menu, and "Upgrade" is the

upgrade menu. Note: The "Effect" menu

function is still under development.

3：Digital zoom in

4：Digital zoom out

5：Image movement (Note: this feature

is only available aer digital zoom in)

Input/Output Interface

1 x USB 2.0: Type A

USB Interface

4X

Digital Zoom

Support

AF

Support

Backlight Compensation

5V (USB power supply)

0.2A

0°C~40°C

-40°C~60°C

1.0W

103.9mm x 26.8mm x 29.9mm (without bracket)

0.2Kg

Input Voltage

Input Current

Operating Temperature

Storage Temperature

Power Consumption

Dimension

Net Weight

General Specification

Camera

Sensor

Scanning Mode

Lens Mount

Lens

Minimum Illumination

Shutter

White Balance

Camera Stand

Physical Privacy Security

Digital Noise Reduction

1/2.8'', CMOS, Effective Pixel: 2.07M

Progressive

M12

Focus: f=2.8mm

0.5 Lux @ (F2.2, AGC ON)

1/30s~1/10000s

Auto, Manual

Standard Damping Rotary Support

Support

2D&3D Digital Noise Reduction

4

Specification

5

Product Details

8

Safety Precautions

9

Maintenance and Troubleshooting

7

Tool Interface

USB Features

USB Protocol

UAC

EPTZ

Windows 7/8/10;

Mac OS X;

Linux;

Android

MJPEG/YUY2/H.264

Up to 1080P30/25

UVC 1.1

Support

Support Panning and Zooming

Operate System

Color System/

Compression

Video Format

1/4''-20 Standard Screw Holes

USB2.0 Type A Interface

Base Stand

For power supply & audio and

video data transmission

 In the process of transportation, storage, and installation, the damage caused

by heavy pressure, violent vibration, and immersion should be prevented.

 The product should be placed on a stable surface or other horizontal

platforms, The shell of this product is made of organic materials; avoid contact

with liquids, gases, or solids that may cause corrosion of the shell.

 Do not disassemble the product without authorized permission.

This product has no parts that consumers can repair by themselves; damage

caused by consumer disassembly is not covered by a warranty.

Operating this equipment in a residential environment may cause radio

interference.

Camera Maintenance

If the camera will not be used for a long time, please disconnect the USB;

Use so cloth to clean camera housing.

Please use the so dry cloth to clean the lens. If the camera is serious dirty,

clean it with diluted neutral detergent. Do not use any type of solvents, which

may damage the lens and affect the image effect;

Unqualified Application

 Do not shooting extreme bright objects, like sunlight, outdoor, lighting, etc.

 Do not operating in unstable lighting conditions, otherwise image will be

flickering.

 Do not operating close to powerful electromagnetic radiation, such as TV or

radio transmitters, etc.

Built-in Physical Privacy Cover

Status Indicator

Microphone

1080P HD Camera

Built-in 6-meter Pickup

Microphone

Built-in 6-meter Pickup

Microphone

Slide the privacy cover le and

right to block or unblock the

lens

Various brackets and tripods

can be easily installed

Various angles of the bracket

can be adjusted freely

1

2

3

4

5

6

7

8

10

11

12

13

15

16

17

18

9

14

Image moves up

Image restore to

default size

Image moves

to the le

Image moves to

the right

Image moves down

079.79.11010083_V1.0www.roc.cowarem

@rocwareav

@Rocware2

@ROCWARE Audio Visual Expert

@ROCWARE Audio Visual Expert

6：Brightness adjustment

7：Contrast adjustment

8：Red gain adjustment

9：Blue gain adjustment

10：Vertical flip

11：Horizontal flip

12：Advanced Settings

13：Restore factory settings

14：Image preview switch

15：Sound volume adjustment

16：Microphone adjustment

(Note: This function is still under

development.)

17：Take photos

18：Video recording (note: this

function is still in development.)

V1.0

USB Webcam

RC19

3

Connecting

2

Mounting

1. Place the webcam on the computer or on the

others screen device.

2. Adjust the webcam so that the mounting

bracket is flush with the back of the screen.

Mounting on The Monitor

1. Locate the 1/4" tripod mounting thread at

the bottom of the universal mounting clip.

2. Screw the tripod into the 1/4" mounting

thread and attach the webcam to the tripod.

3. Place the webcam and tripod in the appropriate position and adjust the bracket according to

the needs.

1. Plug one end of the provided cable into the USB port on the webcam.

2. Plug the other end of the provided cable into an available port on your computer.

• Plug-and-play support will let your computer instantly recognize the webcam.

• If your computer does not instantly recognize the webcam, try plugging into a different USB port or

restart the computer.

3. Open the app you want to use with the webcam.

• The LED light will light up blue when the webcam is in use by an app.

You may need to manually select this webcam and its built-in microphones for your PC system or

soware.

A) Windows

1. Go to Settings > Privacy > Camera and turn on “Allow apps to access your camera”.

2. Turn on each of the listed apps where you want to use the camera. Aer you open the Camera app,

you may need to switch to the ROCWARE RC28 Camera.

B) macOS

1. Go to the Apple menu > System Preferences > Security & Privacy, then choose Camera from the list

on the le side.

2. Locate the app(s) you want to enable camera access for and check the box alongside that app name

to enable camera access for that application.

C) Soware (Zoom or more)

Go to Settings > Video > Camera and choose this webcam.

Mounting on The Tripod

The tripod is not included.

Note

1

Packing List

Webcam

USB CableUser Manual

3. Adjust the webcam angle up and down according to the needs.

V1.0

USB Webcam

RC19

Steady Blue: In working mode

Blinking Blue: Fireware upgrading

6

Controls

Slide to cover the camera lens for privacy. The camera will turn off automatically when blocked by the

privacy cover.

OFF

ON
