Pagina 1/8

Operating Instructions

Mode d’emploi

Bedienungsanleitung

Gebruiksaanwijzing

Istruzioni per l’uso

Manual de instrucciones

Manual de instruções

Visières

615 - 655 - 675 - 975

GENERAL INFORMATION

This canopy hood is designed to be fixed to any rigid vertical surface, over a gas or electric hotplate

and can be used either in the extraction mode (ducted to the outside) or in the recircu-lation mode

(internal recycling). All cookers hood perform better when used in evacuation mode. During winter

time it may be convenient to use the hood in the recycling mode to avoid heat loss from the kitchen.

Before starting the installation, consideration should be given to the difficulties to be found

during installation. The installation work must be undertaken by a qualified and competent

person in conformity to the rules concerning the evacuation of contaminated air.

The manufacturer disclaims all liability for any damage or injury caused as a result of not

following the instructions for installation contained in the following text.

1-SAFETY WARNINGS

1.1 - When used in the extraction mode, the cooker hood ducting must not be connected to a flue

which is used for exhausting fumes from appliances supplied with energy other than electric,

such as a central heating flue or water heating flue.

1.2 - Before connecting to the mains supply ensure that the mains voltage corresponds with the

voltage on the rating plate inside the hood.

1.3 - Connect the cooker hood to the mains via a bipolar switch which has 3mm clearance between

the contacts.

1.4 - For cooker hoods featuring an earth cable, make sure the electric plant of your house is cor-

rectly earthed.

1.5 - Appliance in class II are provided with a double insulation; therefore do not connect then

through earthed plugs but through simple bipolar plugs.

1.6 - When installed, the hood must be positioned at least 65cm above the hotplate.

1.7 - Never do flambé cooking under this cooker hood.

1.8 - Never leave frying pans unattended during use as overheated fat and oil may catch fire.

1.9 - Before carrying out any kind of maintenance or cleaning, disconnect the hood from the mains

supply.

1.10 -If the room where the cooker hood is to be used contains a fuel burning appliance such as a

central heating boiler then this must be of the room sealed or balanced flue type. If other types

of flue or appliance are fitted, ensure that there is an adequate supply of air into the room.

When the cooker hood is used in conjunction with appliances supplied with energy other than

electric, the negative pressure in the room must not exceed 0,04 mbar to prevent fumes being

drawn back into the room by the cooker hood.

2-INSTALLATION INSTRUCTIONS

Some installation systems require the opening and removal of the metal grille panel.

2.1-Instructions for opening and removing the metal grille panel

To open the grille panel, press inwardly on the two slider catches at each side of the grille panel and

the grille will pivot down.

To remove the metal grille, pull forward on the right hand side so that the hinge pin on the back of

the grille will be released from the slot in the side of the casing.

2.2-Wall cabinet fixing

a - Predrilled wall cabinet: fix the hood onto the wall cabinet base panel using the four screws 4.2

x 45 mm (supplied with the fixing kit).

It is not necessary to open the metal grille.

b - No predrilled wall cabinet:

b.1 - If the hood is provided with a paper fixing template, follow the instructions.

b.2 - If the hood is not provided with a paper fixing template, position the hood on the wall

cabinet base panel and pilot drill the 3.5 x 16 mm screws (not supplied with the fixing kit)

from the inside onto the wood.

Product specificaties

Merk:	Roblin
Categorie:	Afzuigkap
Model:	Visière 655
Soort bediening:	Knoppen
Kleur van het product:	Wit
Ingebouwd display:	Nee
Breedte:	598 mm
Diepte:	498 mm
Hoogte:	50 mm
Soort:	Inbouw
Motor vermogen:	138 W
Uitlaat aansluiting diameter:	120 mm
Motor inbegrepen:	Ja
Aantal motors:	2
Maximale afzuigcapaciteit:	400 m³/uur
Afzuigmethode:	Afvoerend/recirculerend
Geluidsniveau (lage snelheid):	56 dB
Aantal lampen:	2 gloeilamp(en)
Type lamp:	Halogeen
Soort vetfilter:	Metaal
Vermogen lamp:	28 W
Geluidsniveau (hoge snelheid:	71 dB
Aantal filters:	2 stuk(s)
Aantal snelheden:	3
Intensieve stand:	Nee
Uitlaat locatie:	Boven
Druk (Pa):	300
