DC~500MHz
13pF±3pF
10MΩ±2%
10:1 (Fixed)
CAT II 300VAC
6pF~24pF
0~50℃，0~80%RH
140±2cm
About 56g
（TechnicalSpecifications）
©2012 RIGOL Technologies, Inc. All Rights Reserved.
RP3500A无源示波器探头
RP3500A Passive Oscilloscope Probe
Probe Head
CAT II:IECMeasurementCategoryII. Inputsmaybeconnectedtomains (upto300VAC)
underCategoryIIovervoltageconditions.
Equipment protected throughout by DOUBLE INSULATION or REINFORCE INSULATION.
Low-frequency compensation
1Connect the probe to the calibration signal output terminal and
signal input terminal at the front panel of the oscilloscope.
2Press Auto at the front panel of the oscilloscope and a 1 kHz square
waveform is displayed on the screen.
3Use the adjustment tool to adjust the low-frequency adjustment
hole to obtain the flattest pulse (As shown in the figures below).
CableLength
You are suggested to compensate the probe so as to match its
characteristics to the oscilloscope. The probes can be adjusted for
low-frequency compensation. Low-frequency compensation needs to
MarkerRings(yellowp
)
, ink,
lightblue anddarkblue
Review this manual carefully to avoid injury and prevent damage to this product or any
products connected to it. To avoid potential hazards, use this product only as specified.
The measurement category of a combination of a PROBE ASSEMBLY and an accessory is the
lower of the measurement category of a combination of the PROBE ASSEMBLY and of the
accessory.
If the PROBE ASSEMBLY is used in a manner not specified by the manufacturer, the
protection provided by the PROBE ASSEMBLY may be impaired.
带宽
衰减比
输入阻抗
输入电容
最大输入
补偿范围
操作环境
探头尺寸
存放环境
探头重量
2
Contact Us
If you have any problem or requirement when using
our products, please contact RIGOLTechnologies,
Inc. or your local distributors, or
visit: www.rigol.com.
联系我们
如您在使用此产品的过程中有任何问题或需
求，可与RIGOL联系：
服务与支持热线：400 620 0002
网址：www.rigol.com
