Manual-1

TTM 54

PERFORMANCE

MIXER

OPERATORS MANUAL

Quick Start

Congratulations! You are now the proud owner of the

best Performance Mixer available. For experienced

turntablists, ninety percent of the operation of the

TTM 54 Performance Mixer is obvious —

however, the TTM 54 also has many unique

features. These new features will be mas-

tered more quickly if you read the entire

manual. Right! We know some of you can’t

resist jumping right in, so please read at least

this portion of the manual. It will help you get

a good start.

• GAIN TRIM:These controls are intended to set

the signal level beforethe Crossfader. Alwaysset the

GAIN TRIMcontrols to indicate an averagesignal level

of +4on the meter with the Program Fadersset to maximum.

Neveruse the GAIN TRIMcontrols to set the output level. Always

use the MASTER LEVELcontrol to set the output level. This is a very

simple thing, yet makes a huge difference in the performance of your mixer.

• EFFECTS: The assignable effects loop allows insertion of a stereo effects processor into:

• Pre-Program Fader PGM 1 ....... Engage PGM 1 EFFECTS only.

• Pre-Program Fader PGM 2 ....... Engage PGM 2 EFFECTS only.

• Post-Crossfader MASTER ....... Engage both PGM 1 and PGM 2 EFFECTS switches.

• Read sections 햵 and 헆 for more information.

• PHONES: The headphone output of the TTM 54 is a high power output stage (unlike most you have used before). There

are some notable differences…

• The headphone output of the TTM 54 delivers very high volume into your headphones.

• To avoid pain, never put headphones on your head and then plug them in.

• Alwaysstart with the PHONES LEVEL turned down and then turn it up to the desired level.

• Because of the high current and low output impedance, never short one side to ground or short left and right

together as is possible with mono cup headphones. Note: Low power headphone stages typically use large

resistors on their outputs, which allow shorting, but prevent high power. The TTM 54 gives you high power but

does not allow shorting.

• MIC LEVEL: For best performance, keep this control at 0 when not in use.

• For instructions on rotating Phono/Line switches to the desired location, see page Manual-6.

• Do not spray cleaner or lubricant into the front of the Program Faders or Crossfader. The fluid will just run out the

bottom of the unit. Never use unapproved cleaner or lubricants such as skateboard wheel lube, as corrosive damage may

result, voiding the warranty. See page Manual-6 for cleaning and replacement instructions and cleaner recommendations.

• Never connect anything except an RS 1 or other approved Rane AC power supply to the thing that looks like a telephone

jack on the rear.This is an 18 VAC center-tapped power unit. Consult the Rane factory for replacement or substitution.

• WEAR PARTS: This product contains the following wear parts subject to the ninety (90) day warranty period described on

page Service-1: FT 45 Active Crossfader & Channel Fader Assembly(3); ST 1 Phono/Line Switch Assembly (2).
