PackageContents

WarningsandCautions

1of2

AssemblyInstructionSheet#IS-TFIK8407VA

ForStyleTFIK8407VA

2016QuoizelInc.

Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.

Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly

recommendthatalicensed,professionalelectricianperformtheinstallation.

Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.Donotsubject

glasspartstoanyshockwhileinoperationorshatteringmayresult.

A

CrossbarAssembly

x1

Pleasegotoforproductcleaningtips.Gototheselection.

(1)A19MediumBasebulb100WMaximum,Alternatebulb(1)23WCFL.

20-30minutes

Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare

present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement

parts.

www.quoizel.comCare+Maintenance

LightSource:

EstimatedAssemblyTime:

Preparation:

Fixturecanonlybemountedinthedirectionindicatedonpage2.

ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.

C

FixtureBody

x1

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-800-645-3184

orvisituson-lineatwww.quoizel.com

B

Alternate

Mounting

screw

x2

STEP1InstallCrossbarAssembly-

A.PassthesupplywiresthroughtheCrossbarAssembly(A).Attach

theCrossbarAssembly(A)totheOutletBoxwiththeheadofthe

GreenGroundScrewfacingyou.SecureitwithOutletBoxScrews

(notincluded).Tightenuntilsnug

Note:UsetheAlternateShorterMountingScrew(B)ifyour

installationrequiresashortermountingscrew.

.

SupplyWires

withGroundWire

OutletBoxScrews

(notincluded)

Outlet

Box

A

Figure1

MountingScrew

orAlternateShort

MountingScrew

CareofTiffanyStyleShade

Anewtiffanylampshadehasanoilfilmappliedtotheshadethatprotectsthetiffanyshadefromscratchesduringshipment.Iftheoilappliedis

tooheavyyoucanremovetheexcessoilfilmwithapapertowel.Gentlywipeawaytheexcessoil.

Forgeneralcleaningoftiffanyshadesuseagentlelemonoil-basedfurniturepolishappliedtoasoftclothandwipegently.

Ifawhitepowderappearsonthesolderedjointsofthetiffanyshadethisisanormaloxidationprocess.Useasmallamountoflemonoilor

mineraloilapplieddirectlytooxidizedareasandthesolderedareawillreturntolikenew.

STEP2TestFittingBackplatetoCrossbarAssembly-

A.RemovemountingballsfromtheCrossbarAssembly(A).Fitthe

backplateonFixtureBody(C)totheCrossbarAssembly(A)and

securewithmountingballs.Note:ThebackplateonFixtureBody(C)

(Step2Continued)

shouldbesnugagainstthewallandthemountingballs.Ifnot,adjust

thelengthofthemountingscreworalternateshortmountingscrew

C

MountingBall

A

Backplate

HexNutand

LockWasher

Figure2

MountingScrew

orAlternateShort

MountingScrew

ontheCrossbarAssembly

(A)byunscrewingthe

preassembledhexnutand

lockwasherandthen

screwingthemounting

screwsoralternateshort

mountingscrewsinorout

ofthecrossbaruntilthe

correctlengthisachieved.

Oncethebackplateon

FixtureBody(C)issecure,

removethemountingball

andFixtureBody(C)and

proceedtoStep3.

STEP3-WireConnections

A.Usestandardwireconnectors(notincluded)tomakeallwire

connections.Twistconnectorsuntilwiresaretightlyjoinedtogether.

Wrapeachconnectionwithapprovedelectricaltapeandcarefully

stuffalltheconnectedwiresintotheOutletBox.

Whitewire

fromsupply

Whitewire

fromfixture

Blackwirefrom

supply(orRed)

Blackwire

fromfixture

Groundwire

fromsupply

Groundwire

fromfixture

Figure3

ReleasedDate:2016-07-29
