Pleasegotoforproductcleaningtips.Gototheselection.
(2)A19MediumBaseBulbs75WMaximum
20-30minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
www.quoizel.comCare+Maintenance
LightSource:
EstimatedAssemblyTime:
Preparation:
ToolsRequired:None.
WarningsandCautions
1of2
AssemblyInstructionSheet#IS-TF3341T
ForStyleTF3341T
2017QuoizelInc.
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly
recommendthatalicensed,professionalelectricianperformtheinstallation.
Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.
CareofTiffanyStyleShade
Anewtiffanylampshadehasanoilfilmappliedtotheshadethatprotectsthetiffanyshadefromscratchesduringshipment.Iftheoilappliedis
tooheavyyoucanremovetheexcessoilfilmwithapapertowel.Gentlywipeawaytheexcessoil.
Forgeneralcleaningoftiffanyshadesuseagentlelemonoil-basedfurniturepolishappliedtoasoftclothandwipegently.
Ifawhitepowderappearsonthesolderedjointsofthetiffanyshadethisisanormaloxidationprocess.Useasmallamountoflemonoilor
mineraloilapplieddirectlytooxidizedareasandthesolderedareawillreturntolikenew.
6CORPORATEPARKWAY
GOOSECREEKSC29445
wwwquoizelcom
,.
..
ThankyouforpurchasingaQuoizelproduct.
Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-800-645-3184
orvisituson-lineatwww.quoizel.com
A.InserttheGlassPanelintotheFrameandsecurethe
GlassPanelwithTabsattheedgesoftheFrame.
B.ThreadtheSocketAssemblyontotheBaseandmakesure
socketsareparallelwithBase.Handtightenuntilsnug.
C.ThreadthehexnutendoftheNipplewithHexNutintothe
hexcouplingonthetopcenteroftheSocketAssembly.By
usingthepliers,threadthehexnutagainstthehex
couplingandhandtightenuntilsnug.
D.PlacetheSpacerTubeandtheCheckRingoverthetop
endoftheNippleandsecurewiththeSmallKnurledNut.
Handtightenuntilsnug.
E.ThreadtheBigKnurledNutontothetopendoftheNipple
andadjustittoproperlocationforrestcomponents.Place
theFlatWasher,theShade,theBigCap,theSmallCap
andtheRubberWasheroverthetopendoftheNipple.
MakeShadeisparallelwithBase.SecurewiththeFinial
andhandtightenuntilsnug.
F.Insertbulbsontosocketsandscrewsnuglyintoplace.
Yourfixtureisnowassembledandreadytouse.Enjoy!
Incorrect
base/socket/
shadeOrientation
Correct
base/socket/
shadeOrientation
Cord
Base
x1
Bulb(not
included)
Socket
Assembly
x1
4”LNipple
withHexNut
x1
3.5”L
SpacerTube
x1
FlatWasher
x1
BigKnurled
Nutx1
Small
KnurledNut
x1
CheckRing
x1
Shade
x1
BigCap
x1
SmallCap
x1
Finial
x1
GlassPanel
x4
Frame
x1
Tab
Tab
ReleasedDate:2017-10-11
RubberWasher
x1
