User’s Manual of WGS Managed Series

Industrial Wall-mount

Managed Gigabit Ethernet

Switch

WGS-4215 Series

WGS-804HPT

User’s Manual of WGS Managed Series

Trademarks

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no

warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for

a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability

for any inaccuracies or omissions that may have occurred.

Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of

PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes

no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to

this User's Manual and/or to the products described in this User's Manual, at any time without notice.

If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and

suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be

required to take adequate measures.

Energy Saving Note of the Device

This power required device does not support Standby mode operation. For energy saving, please remove the power cable to

disconnect the device from the power circuit. In view of saving the energy and reducing the unnecessary power consumption, it

is strongly suggested to remove the power connection for the device if this device is not intended to be active.

WEEE Warning

To avoid the potential effects on the environment and human health as a result of the presence of hazardous

substances in electrical and electronic equipment, end users of electrical and electronic equipment should

understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted

municipal waste and have to collect such WEEE separately.

Revision

User’s Manual of PLANET WGS Managed Series

Models: WGS-804HPT, WGS-4215-8T, WGS-4215-8T2S, WGS-4215-8P2S, WGS-4215-16P2S

Revision: 1.3 (January. 2023)

Part No: EM-WGS-804HPT_WGS-4215 series_v1.3

Product specificaties

Merk:	Planet
Categorie:	Niet gecategoriseerd
Model:	WGS-4215-16P2S
Kleur van het product:	Zwart
Gewicht:	1004 g
Breedte:	245 mm
Diepte:	140 mm
Hoogte:	24.4 mm
Materiaal behuizing:	Metaal
Internationale veiligheidscode (IP):	IP40
LED-indicatoren:	Activity, Link, PoE, Power
Snelstartgids:	Ja
Vermogensverbruik (max):	253 W
DC voltage input:	48 - 56 V
Certificering:	FCC Part 15 Class A, CE
Netwerkstandaard:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ondersteunde beveiligingsalgoritmen:	SNMP, SNMPv3
Temperatuur bij opslag:	-40 - 85 °C
Upgraden van firmware mogelijk:	Ja
Web-gebaseerd management:	Ja
Luchtvochtigheid bij opslag:	5 - 95 procent
Reset button:	Ja
MAC adres filtering:	Ja
Ophangsysteem voor aan de muur:	Ja
Quality of Service (QoS):	Ja
VLAN=ondersteuning:	Ja
Auto MDI/MDI-X:	Ja
Virtuele LAN-functies:	Private VLAN, Protocol-based VLAN, Stacked VLAN, Tagged VLAN, Voice VLAN
Access Control List (ACL):	Ja
IPv4- & IPv6-functies:	IPv6 Telnet
Power over Ethernet (PoE):	Ja
Switchingcapaciteit:	36 Gbit/s
MAC-adrestabel:	8000 entries
Datastroombeheer:	Ja
Rate limiting:	Ja
Aantal VLANs:	4094
IGMP snooping:	Ja
Switch type:	Managed
Multicast-ondersteuning:	Ja
Aantal basis-switching RJ-45 Ethernet-poorten:	16
Netstekker:	Terminal block (3-pin)
Switch-laag:	L2
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Packet buffergeheugen:	4.1 MB
Throughput:	26.78 Mpps
Jumbo Frames ondersteuning:	Ja
Port mirroring:	Ja
Spanning tree protocol:	Ja
Verbindingsaggregatie:	Ja
Full duplex:	Ja
Koperen ethernetbekabelingstechnologie:	10BASE-T, 100BASE-FX, 100BASE-TX, 1000BASE-LX, 1000BASE-SX, 1000BASE-T
DHCP-functies:	DHCP snooping
SSH/SSL support:	Ja
Warmtedissipatie:	868 BTU/h
Bedrijfstemperatuur (T-T):	-10 - 60 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 95 procent
Totaal Power over Ethernet (PoE)-budget:	240 W
Jumbo frames:	10000
Aantal geïnstalleerde SFP modules:	2
DIN rail bevestiging:	Ja
Hoeveelheid Power over Ethernet (PoE) ports:	8
Broadcast stormbeheer:	Ja
Bescherming lus:	Ja
Store-and-forward:	Ja
Vermogen per poort Power over Ethernet (PoE):	36 W
Authenticatie type:	HWTACACS+, RADIUS
IP-MAC-Port binding:	Ja
ARP-inspectie:	Ja
Aantal trunks:	1
Traffic-classificatie:	Ja
BPDU filtering / bescherming:	Ja
Authenticatie:	Poortgebaseerde authenticatie
Algoritmen wachtrijplanning:	Priority queuing (PQ), Weighted Round Robin (WRR)
GARP VLAN Registratieprotocol (GVRP):	Ja
Multicast Listener Discovery (MLD) snooping:	v1/v2
IGMP-vermeldingen:	256
MLD-vermeldingen:	256
