User’s Manual of GS-4210-8UP2S/GS-4210-16UP4C/GS-4210-24UP4C/

GS-4210-16UP8T4X/GS-4210-24UP4X

16/24-Port 10/100/1000T 802.3bt PoE++

plus 4-Port Gigabit TP/SFP Combo

Managed Switch

8-/16-/24-Port 1000T 802.3bt PoE

Managed Ethernet Switch

GS-4210-8UP2S

GS-4210-16UP4C

GS-4210-24UP4C

GS-4210-16UP8T4X

GS-4210-24UP4X

User’s Manual of GS-4210-8UP2S/GS-4210-16UP4C/GS-4210-24UP4C/

GS-4210-16UP8T4X/GS-4210-24UP4X

Trademarks

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no

warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for

a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability

for any inaccuracies or omissions that may have occurred.

Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of

PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes

no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to

this User's Manual and/or to the products described in this User's Manual, at any time without notice.

If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and

suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

CE Mark Warning

This device is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference.

Energy Saving Note of the Device

This power required device does not support Standby mode operation. For energy saving, please remove the power cable to

disconnect the device from the power circuit. In view of saving the energy and reducing the unnecessary power consumption, it

is strongly suggested to remove the power connection for the device if this device is not intended to be active.

WEEE Warning

To avoid the potential effects on the environment and human health as a result of the presence of hazardous

substances in electrical and electronic equipment, end users of electrical and electronic equipment should

understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted

municipal waste and have to collect such WEEE separately.

Revision

PLANET 8-Port 10/100/1000T 802.3bt PoE + 2-Port 100/1000X SFP Managed Ethernet Switch &

16-/24-Port 10/100/1000T 802.3bt PoE++ plus 4-Port Gigabit TP/SFP Combo Managed Switch &16/24-Port 10/100/1000T

802.3bt PoE++ +4-Port 10G SFP+ User's Manual

FOR MODELS: GS-4210-8UP2S/GS-4210-16UP4C /GS-4210-24UP4C/GS-4210-16UP8T4X/GS-4210-24UP4X

REVISION: 3.2 (June, 2024)/Part No: EM-GS-4210-8UP2S_16UP4C_24UP4C_GS-4210-16UP8T4X_GS-4210-24UP4X_v3.2

Product specificaties

Merk:	Planet
Categorie:	Niet gecategoriseerd
Model:	GS-4210-24UP4C
Kleur van het product:	Blauw
Gewicht:	5000 g
Breedte:	440 mm
Diepte:	300 mm
Hoogte:	44.5 mm
Materiaal behuizing:	Metaal
LED-indicatoren:	Ja
Aan/uitschakelaar:	Ja
Vormfactor:	1U
Meegeleverde kabels:	RS-232
Compatibele geheugenkaarten:	Niet ondersteund
Snelstartgids:	Ja
Inclusief AC-adapter:	Ja
Vermogensverbruik (max):	900 W
Certificering:	FCC Part 15 Class A, CE, LVD
Netwerkstandaard:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1af, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ondersteunde beveiligingsalgoritmen:	SNMP, SSH, SSL/TLS
Temperatuur bij opslag:	-10 - 70 °C
Aantal ventilatoren:	3 ventilator(en)
Upgraden van firmware mogelijk:	Ja
Web-gebaseerd management:	Ja
Luchtvochtigheid bij opslag:	5 - 95 procent
Reset button:	Ja
Rack-montage:	Ja
MAC adres filtering:	Ja
Quality of Service (QoS):	Ja
VLAN=ondersteuning:	Ja
Auto MDI/MDI-X:	Ja
Virtuele LAN-functies:	Private VLAN, Tagged VLAN, Protocol-based VLAN
Access Control List (ACL):	Ja
Power over Ethernet (PoE):	Ja
Switchingcapaciteit:	56 Gbit/s
MAC-adrestabel:	8000 entries
10G support:	Nee
Datastroombeheer:	Ja
Rate limiting:	Ja
IGMP snooping:	Ja
Switch type:	Managed
Multicast-ondersteuning:	Ja
Aantal basis-switching RJ-45 Ethernet-poorten:	28
Montagebeugels meegeleverd:	Ja
Switch-laag:	L2/L4
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Throughput:	41.67 Mpps
Jumbo Frames ondersteuning:	Ja
Port mirroring:	Ja
Spanning tree protocol:	Ja
Verbindingsaggregatie:	Ja
Full duplex:	Ja
Koperen ethernetbekabelingstechnologie:	10BASE-T, 100BASE-T, 1000BASE-T
DHCP-functies:	DHCP server, DHCP client
SSH/SSL support:	Ja
Rubberen voetjes:	Ja
Beheerprotocollen:	SNMP
Warmtedissipatie:	3070 BTU/h
Statische poort beveiliging:	Ja
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Bedrijfstemperatuur (T-T):	0 - 50 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 95 procent
Code geharmoniseerd systeem (HS):	85176990
Totaal Power over Ethernet (PoE)-budget:	600 W
Aantal Power over Ethernet plus (PoE +)-poorten:	24
Jumbo frames:	10000
Hoeveelheid Power over Ethernet (PoE) ports:	24
MIB-ondersteuning:	RFC 1213 MIB-II, RFC 1215 Generic Traps, RFC 1493 Bridge MIB, RFC 2674 Bridge MIB Extensions RFC 2737 Entity MIB (v2), RFC 2819 RMON (1, 2, 3, 9), RFC 2863 Interface Group MIB, RFC 3635 Ethernet-like MIB
Broadcast stormbeheer:	Ja
Bescherming lus:	Ja
Store-and-forward:	Ja
System event log:	Ja
Vezel-optische connector:	LC
Rekbevestigingspakket:	Ja
Fiber ethernet cabling technologie:	100BASE-FX, 1000BASE‑LX, 1000BASE‑SX
MAC-adres zelfverouderende functie:	Ja
MAC-adres zelflerende functie:	Ja
Aantal Combo SFP-poorten:	4
Auto-sensing:	Ja
Transmissie afstand (max):	2 km
Aantal wachtrijen:	8
ARP-inspectie:	Ja
Aantal trunks:	4
Traffic-classificatie:	Ja
BPDU filtering / bescherming:	Ja
Authenticatie:	MAC-based authentication, Port-based authentication
Aantal gefilterde multicast-groepen:	256
Fiber type:	Multimode
Admin-edge-port:	Ja
