GPN-400AXV

GPON HGU with 4-Port GbE, 3000Mbps 802.11AX Wireless

GPON

• 1xSC/UPCtypeGPONport(compatiblewithEPON)

• Upto2.5Gbpsdownstreamand1.25Gbpsupstream

• Transmissiondistanceupto20km

• Opticaltransmitpower:0.5~5dBm,receivesensitivity:≤

-28dBm

• SupportsITU-TG.984/G.988,IEEE802.3ahstandards

• AutomaticswitchingbetweenEPONandGPONforhybrid

deployment

Ethernet

• 802.1QVLAN,andQoSforvirtualLANtaggingandtrafc

prioritization

• Broadcaststormprotectiontopreventandlimitbroadcast

trafc

• Bandwidthcontroltomanageandallocatenetwork

bandwidth

• IGMPsnooping/proxyforefcientmulticasttrafc

management

• IPv4andIPv6protocolssupported

VoIP

• 1FXSport,supportingSIPandH.248protocols

• CompatiblewithvoicecodecsincludingG.711,G.729and

G.723

• SupportsT.38andG.711pass-throughforfax

Wireless

• Upto3000Mbpsbandwidth

• Compatiblewith802.11axWi-Fi6

• Backwardcompatiblewith802.11b/g/n/ac

• Compatibletoequipmentworkingon2.4GHzand5GHz

QoS

• IEEE802.3xowcontrolforfull-duplexcommunication

• QueueschedulingalgorithmsincludingWRR,StrictPriority,

andFIFO

Multicast

• IGMPsnoopingv1/v2/v3

Delivering High-demanding Service Connectivity for ISP / Triple Play

Devices

PLANET GPN-400AXVisa high-performanceGPONWi-FiONU(opticalnetwork

unit)equippedwithoneGPONport,four10/100/1000MbpsRJ45LANports,oneFXS

RJ11voiceport,andaUSBinterface.FeaturingIEEE802.11ax/ac/nWi-Fi6dual-band

technology,itdeliversexceptionalwirelessperformanceupto3000Mbps.Designed

forresidentialand smallbusinessusers,it offersanidealsolution forhigh-speed

fiberbroadbandaccessandvalue-addedservicessuchasIPTV,VoIP,andultra-fast

Internet.WhenpairedwithPLANETGPL-8000GPONOLT,theGPN-400AXVensures

a forFTTHdeployments.robust and scalable GPON solution

GPON 2.5G/1.25G

4 x GbE LAN

Dual band Wi-Fi 6

GPON

Transmission 20km

OLT compatible

RJ11 VoIP

2.5Gbps

1.25Gbps

GPN-400AXV

PON

Fiber To The Home

IPTV

Phone

Laptop

1:128 Splitter

GPON OLT

11.5 miles

1000BASE-T UTP

PON

Passive Optical Network

GPN-400ACV

IPTV

Laptop

Phone

IPTV

VoIP

Internet

GPN-400AXV

• IGMPproxyfunction

Security

• FirewallwithMAC/IP/Port/URL/Domainltering

• DDoSattackprotection

Wireless

• Upto3000Mbpsbandwidth

• Compatiblewith802.11axWi-Fi6

• Backwardcompatiblewith802.11b/g/n/ac

• Compatibletoequipmentworkingon2.4GHzand5GHz

PhysicalHardware

• 4x10/100/1000MbpsGigabitEthernetports

• 1xFXSvoiceport

• 1xUSBinterface

• 5xexternalantennas(for2.4GHzand5GHz)

• Dimensions:185x135x36mm(excludingantennas)

• Powerinput:DC12V/1.5A,powerconsumption<18W

Features

• DynamicBandwidthAllocation(DBA)support

• IEEE802.3xowcontrol

• WR,SP,andFIFOqueueschedulingalgorithmsfortrafc

management

• Port-basedVLANandIEEE802.1QVLAN

• FirewalllikeMAC/IP/Port/URL/Domainltering

• DDoSprotectiontosafeguardagainstdistributeddenial-of-

serviceattacks

• Loopdetectiontopreventnetworkloops

• Dying-gaspmechanismforgracefuldeviceshutdown

• TypeBdual-homingprotection

Management

• Web,Telnet,TR-069,OMCI,andOAMremotemanagement

• FirmwareupgradeviaTFTP,Web,TR-069,andOLT

Wi-Fi 6 AX3000 Delivers Reliable Wireless Performance

Withbuilt-indual-bandWi-Fi6andveexternalantennas,theGPN-400AXVsupports

atotalwirelessspeedof upto 3000Mbps.It supportsMU-MIMOand Wi-FiMesh,

offering ,idealformodernsmarthomeandofcegreater capacity and lower latency

environments.

Flexible Gigabit LAN and USB Connectivity

FourGigabitEthernetports andone USBinterface ensurefast and stable wired

connectionsfordeviceslikedesktops,NAS,andsmartTVs.TheUSBport also

supportsadditionalusecasessuchas4Gdonglesorlesharing.

Built-in FXS Voice Port

TheGPN-400AXVincludesoneFXSportsupportingSIPandH.248protocols.This

allowsintegrationintoIPvoicesystemsandhelpsreducecallcostsfor long-distance

and remote ofce communications.

IPv4 and IPv6 Dual Stack Capability

Thedeviceis fullycompatible withbothIPv4 andIPv6, makingitafuture-proof

choice for ISPsplanningIPv6migration.

Comprehensive Management and Security

ItsupportsWebGUI,Telnet,TR-069,OMCI,andOAMmanagementmethods,plus

firmwareupgradesviaremoteplatforms.IntegratedfirewallandACLfeaturesensure

network security and reliable operation.

GPN-400AXV

Applications

Seamless 2.5G GPON Connectivity for Residential Triple-Play and FTTH Services

PLANETGPN-400AXVisafullyintegratedGPONONUthatcombineshigh-speedberaccess,GigabitEthernet,dual-bandWi-Fi6,andvoicefunctionality,

makingitidealforsmarthomes,SOHOenvironments,andcommercialspaces.SupportingbothGPONandEPONauto-detectionwith2.5Gbpsdownstream

and1.25Gbpsupstreamtransmission,italsofeaturesAX3000-classWi-Fi6,providingsimultaneous2.4GHzand5GHzbandstoensuresmoothandstable

connectionsacrossmultipledevices.

Whetherdeployed in high-density residential communities,hotels, orsmall to medium-sized businesses,the GPN-400AXV delivers reliablenetwork

performanceandflexiblemanagement.WithadvancedfeaturessuchasVLAN,QoS,ACL,andfirewallsupport,itsecuresinternalnetworksandprioritizes

criticalservices.Wi-FiMesh, MU-MIMO,and multipleSSIDfeaturesfurtherenhance wireless coverageand speed,meeting thegrowing demand for

seamlessconnectivity.

Inaddition, thebuilt-inFXSportsupports SIPandH.248protocols, allowingforeasy integrationwithresidentialor enterprise VoIPsystems, reducing
