Quick Installation Guide for Ethernet Lightning Arrest Box

Thank you for purchasing PLANET Ethernet Lightning Arrest Box ELA-100, the Eth-

ernet Lightning Arrest Box package shall contain following contents:

Check the contents of your package for following parts:

 Ethernet Lightning Arrest Box x1

 Quick Installation Guide x1

 Ground cable x1

If any of these pieces are missing or damaged, please contact your dealer imme-

diately, if possible, retain the carton including the original packing material, and

use them against to repack the product in case there is a need to return it to us

for repair.

Please refer to following procedure and picture to install the Ethernet Lightning

Arrest Box between two Ethernet devices.

Step 1:

In the right side, please use ground cable from package to connect the screw

and ground.

Step 2:

Please connect rst Ethernet device to the protected port that near the screw

through the UTP cable.

Step 3:

Please connect second Ethernet device to un-protected port from other

side of Ethernet Lightning Arrest Box.

Quick Installation Guide for Ethernet Lightning Arrest Box

1. Please install this device at outdoor with shelter.

2. This Ethernet Lightning Arrest Box must be earthed. If not. this device may

with electric shock and cause damage.

Figure 1: ELA-100 Application

Notice:

Quick Installation Guide for Ethernet Lightning Arrest Box

Model ELA-100

Ethernet Interface 2 passive 10/100/1000 Ethernet Ports

Ground 1 ground position

DC spark-over voltage 230V, ±20%

Nominal impulse discharge

current ( wave 8/20μs)

20KA

Arc Voltage at 1A ~35V

Glow to arc transition current ~1A

Glow voltage ~200V

Dimension (W x D xH) 65 x 42 x 20mm

Weight 80g

Operate/Storage environment -40~70 Degree C, 5%~90%RH

Table 1: Specification of ELA-100
