4. Specications

Product

Model CAM-AHD325 CAM-AHD425

Camera

Sensor SONY 1/2.8” 2MP CMOS

Effective Picture

Elements

1920(H) x 1080(V) @ 30fps

Lens Furnished Board Lens 3.6mm/F1.2

Minimum

Illumination

0.01 lux @ F1.2, 0 lux with built-in

IR LED

LED

IR LED 36pcs Φ5 LED 24pcs Φ5 LED

IR Project Distance 30 meters 25 meters

Video & Audio

Hybrid Signal Output AHD/TVI/CVI/CVBS mode

S/N Ratio More than 52 dB

Day & Night Auto/Color/B/W/EXT

D-WDR ON/OFF

White Balance ATW/MWB

Gamma

Characteristics

0.45

Exposure Mode Globe/Center/BLC/FLC

Shutter Speed 1/25s~1/45,000s

Digital Noise

Reduction

2D DNR

Defog Auto/ON/OFF

AGC Auto/Manual

Transmission

Distance

Coaxial transmission common 75-3

cable up to 300-500 meters

Environment

Operating

Temperature

-30 to 50 degrees C

Humidity ≤85%RH

Power Supply 12V DC, 1A

Water Resistance IP66 IP65

Dimensions

(W x D x H)

83 x 192 x 77

98 x 110 x 77

Further Information

If you have any other question, please contact the dealer

where you purchased this product or you can contact

PLANET directly at the following email address:

support_ica@planet.com.tw

– 1 – – 2 –

– 3 – – 4 –

1. Packet Contents

VERIFY THE CONTENTS INSIDE THE PACKAGE BOX

The package should contain the items plus CAM-AHD325/

CAM-AHD425. If any item is missing or damaged, please

contact the seller immediately.

Quick installation guide x 1

Hex wrench x 1

(CAM-AHD325 only)

CAM-AHD325 CAM-AHD425

Screw packet for each model x 1

2. Physical Introduction

CAM-AHD325 CAM-AHD425

IR LED

IR LED Sunshield

Video Output

Power Input

OSD Control Button

Connector Description

Power Input Connect to a 12V DC power adapter.

Video Output BNC connector for analog video output.

OSD Control

Button

Description

H AHD Mode

T TVI Mode

C CVI Mode

A CVBS Mode

Press & Direction

Control

OSD Configuration

3. Hardware Installation

1. Place the camera in a suitable location and attach with

screws.

2. Adjust the camera to the correct direction.

3. Connect a 12V DC power adapter to the power input

connector.

4. Connect to the DVR and select your channel. Next, select

required mode via the OSD control button and hold the

button for about 5 seconds to take effect. After that, the

image of camera will be shown on the channel.

5. Press the OSD control button to enter the main menu of

OSD function for conguration

Note

Before connecting the power adapter to the

camera, please make sure the power output

voltage is 12V DC (max. ±5%). If you are not

sure of this part, we suggest you use a 12V

DC switching power adapter. It can provide

stable power output.

3.1 OSD Function

3.2 Setting Steps

1. Exposure

2. Digital Noise Reduction

3. Special Functions

4. Adjust
