FLEXIBLE CONDUIT CLAMP

TILE BRIDGE

COVER PLATE

SECONDARY ATTACHMENT

POINT

SPEEDWING

™

MOUNTING

ARMS

INSTALLATION AID/

PAINT MASK

BAFFLE

GRILLE

GRILLE SAFETY RESTRAINT

[BOX CONTENTS]

1 SPEAKER

1 FLEXIBLE CONDUIT CLAMP

1 COVER PLATE

1 GRILLE

1 INSTALLATION AID/ PAINT MASK

MAX: 1.6”MIN: 0.035”

CEILING THICKNESS TOLERANCES

All CI Series speakers include self-resetting solid-state PTC protection circuits. This

unique system is able to detect when the speaker is being over-driven and lowers the

speaker volume until the problem is corrected. The PTC device then resets itself for

normal operation.

Regardless of application, serious audiophile listening or home theater, we recommend

that you take the time to read this manual thoroughly before connecting speakers to your

amplier or receiver. In the highly unlikely event that you should experience a problem

with set-up or operation, please contact one of our authorized dealers for assistance, or

contact us directly.

Phase Technology

®

Corporation

8005 W. 110th St., Suite 208

Overland Park, KS 66210

855.663.5600 (Domestic)

+1.913.663.5600 (International)

913.663.3200 (Fax)

SAFETY INSTRUCTIONS 2

DROPTILE CEILING INSTALL 3

SHEETROCK CEILING INSTALL 4

PRE-CONSTRUCTION BRACKET INSTALL 5

CARING FOR YOUR SPEAKER 5

MAINTENANCE AND SERVICE 6

WARRANTY 6

SPECIFICATIONS 6

CIX IN-CEILING

OWNER’S MANUAL: CI520 • CI620 • CI820
