Installation

Instructions

Dispensing Towers

Draft Arm, Lucky, Panther or Tee Towers

PERLICK CORPORATION 8300 W. Good Hope Road, Milwaukee, WI 53223 • 800.558.5592 • perlick.com

Form No. Z2351

Rev. 11.2.22

Tee Tower

Lucky Tower

Panther Tower

Draft Arm

PERLICK CORPORATION 8300 W. Good Hope Road, Milwaukee, WI 53223 • 800.558.5592 • perlick.com

PRODUCT INSTALLATION INSTRUCTIONS  Dispensing Towers

DISPENSING TOWERS

DRAFT ARMS, 2-6 FAUCET TEE TOWERS, LUCKY AND PANTHER TOWERS

TABLE OF CONTENTS

Beer and Wine Kits ............................................................................................................................................................................... 3

Tools and Materials Required ......................................................................................................................................................... 3

Dispensing Kit Component Parts .................................................................................................................................................. 3

Air Scoops for Field Retrot Kits ................................................................................................................................................... 7

General Installation and Field Retrot Installation ............................................................................................................. 8

Safety Information ............................................................................................................................................................................... 8

About Wine Dispensing ..................................................................................................................................................................... 8

Air Distributor and Air Scoop Installation - Field Retrot Instructions ...................................................................... 9

Air Tubing to Air Scoop Attachment ............................................................................................................................................ 9

Air Distributor Assembly Attachment to Cabinet .................................................................................................................... 9

Draft Arm and Tee Tower Instructions ..................................................................................................................................... 10

Draft Arm Preparation .................................................................................................................................................................... 10

Tee Tower Preparation .................................................................................................................................................................... 10

Mounting Draft Arms or Tee Towers to a Cabinet Top ........................................................................................................ 10

Mounting Draft Arms or Tee Towers to a Counter Top ....................................................................................................... 11

Attaching Faucets to Draft Arms or Tee Towers .................................................................................................................... 11

Mounting the Beer/Wine Drainer to a Cabinet Top ............................................................................................................. 11

Mounting the Beer/Wine Drainer to a Counter Top ............................................................................................................ 12

Running the Air Scoop Tubing to the Draft Arms or Tee Towers .................................................................................... 12

Attaching the Beer Line to the Draft Arms or Tee Towers ................................................................................................. 13

Attaching the Wine Line to Draft Arms or Tee, Lucky or Panther Towers .................................................................... 13

Attaching the Gas Line Tubing ................................................................................................................................................... 14

Attaching the Tapping Hole Covers .......................................................................................................................................... 14

Attaching the Air Distributor Cover ........................................................................................................................................... 14

Checking the System for Leaks ................................................................................................................................................... 14

Lucky and Panther Tower Instructions ................................................................................................................................... 15

Lucky and Panther Tower Preparation ..................................................................................................................................... 15

Mounting Lucky or Panther Towers to a Cabinet Top ......................................................................................................... 15

Mounting Lucky or Panther Towers to a Counter Top ........................................................................................................ 15

Attaching Faucets to Lucky or Panther Towers ..................................................................................................................... 15

Mounting the Beer/Wine Drainer to a Cabinet Top ............................................................................................................ 16

Mounting the Beer/Wine Drainer to a Counter Top ............................................................................................................ 17

Running the Air Scoop Tubing to the Lucky or Panther Towers ..................................................................................... 17

Attaching the Beer Line to the Lucky or Panther Towers .................................................................................................. 18

Attaching the Gas Line Tubing .................................................................................................................................................... 18

Attaching the Tapping Hole Covers .......................................................................................................................................... 18

Attaching the Air Distributor Cover .......................................................................................................................................... 19

Checking the System for Leaks ................................................................................................................................................... 19

Appendix ............................................................................................................................................................................................... 20
