Peerless-AV DST940-BTB Handleiding

Peerless-AV Flat panel steun DST940-BTB

Bekijk gratis de handleiding van Peerless-AV DST940-BTB (12 pagina’s), behorend tot de categorie Flat panel steun. Deze gids werd als nuttig beoordeeld door 2 mensen en kreeg gemiddeld 4.7 sterren uit 1.5 reviews. Heb je een vraag over Peerless-AV DST940-BTB of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/12

2016-09-13 #:126-9148-2 2017-05-15

DST940-BTB

37" - 46"

(94 - 117 cm)

75 lb x4

(34 kg) x4

MAX

2016-09-13 #:126-9148-2 2017-05-15

ENG - Before installing make sure the supporting surface will support the combined load of the equipment and

hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.

Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to safely lift

and position equipment. This product is intended for indoor use only. Use of this product outdoors could lead to

product failure or personal injury. For support please call customer care at 1-800-865-2112.

WARNING

Symbols

Símbolos

Symboles

Symbole

Symbolen

Simboli

Symboly

Símbolos

Semboller

ENG

ESP

FRN

DEU

NEL

ITL

ČEŠ

SLK

POR

TÜR

WARNING

ADVERTENCIA

ADVERTISSEMENT

ACHTUNG

WAARSCHUWING

AVVERTENZA

VÝSTRAHA

AVISO

UYARI

ENG

ESP

FRN

DEU

NEL

ITL

ČEŠ

SLK

POR

TÜR

Skip to step.

Continúe con el

paso.

Passez à l’étape.

Weiter mit Schritt.

Ga door naar stap.

Vai al passo.

P esko te na krok.ř č

Presko te na krok.č

Saltar para o

passo.

Su ad ma geç.ı

ENG

ESP

FRN

DEU

NEL

ITL

ČEŠ

SLK

POR

TÜR

Screws must get at least three

full turns and ﬁ t snug.

Los tornillos tienen que dar,

por lo menos, tres vueltas

completas y quedar ajustados.

Il faut effectuer au moins trois

tours de vis complets et bien

serrer les vis.

Schrauben sind mindestens drei

volle Umdrehungen einzudrehen

und müssen fest anliegen.

De schroeven moeten ten

minste drie hele slagen worden

aangedraaid en stevig vastzitten.

Girare tre volte le viti che

devono risultare aderenti.

Šrouby se musí oto it minimáln č ě

t i plné otá ky a pln dosednout.ř č ě

Skrutky sa musia oto i aspo č ť ň

tri celé otá ky a tesne dosadnú .č ť

Os parafusos devem completar,

no mínimo, três voltas

completas e ajustar-se no local.

Vidalar en az üç tam dönü ş

yapmal ve s k oturmal dı ı ı ı ır.

ENG

ESP

FRN

DEU

NEL

ITL

ČEŠ

SLK

POR

TÜR

Do not overtighten screws.

No apriete de más los tornillos.

Ne pas trop serrer les vis.

Ziehen Sie die Schrauben nicht zu

fest an.

Draai de schroeven niet te strak aan.

Non stringere troppo le viti.

Šrouby neutahujte p íliš siln .ř ě

Skrutky neu ahujte príliš silno.ť

Não apertar demasiado os parafusos.

Vidalar gere inden fazla s kmay n.ığı ı

ENG

ESP

FRN

DEU

NEL

ITL

ČEŠ

SLK

POR

TÜR

2016-09-13 #:126-9148-2 2017-05-15

(

)

tilt plate

(

)

M5 x 12mm screw

(

)

retaining collar

(

)

tilt box

(

)

washer

(

)

4mm allen wrench

Parts List

PLB-1

Part #Description Qty

Atilt box 2 100-1128

Btilt plate 4 100-1047

CM5 x 12mm socket pin screw 8 520-1064

Dwasher 2 540-9432

Eretaining collar 3 1800-375

FM4 x 12mm socket pin serrated washer screw 16 520-1079

GM4 x 25mm socket pin serrated washer screw 16 520-1082

HM6 x 12mm socket pin screw 16 520-1050

IM6 x 25mm socket pin screw 16 520-1211

J#10 washer 16 540-9400

KM8 x 25mm socket pin screw 16 520-1101

LM8 x 12mm socket pin screw 16 520-1724

M5/16 SAE washer 32 540-9406

Nspacer 32 600-1215

O4mm allen wrench 1 560-9646

P6" extension column 2 026-1014

Qdual cross support 1 139-1015

R4.5" hex bolt 1 520-9548

S3/8"-16 nylock nut 1 530-9310

TM10 x 15mm penta pin screw 16 520-9263

Uadapter bracket 8 202-1655

VM10 x 2" tool driver penta pin 1 520-9260

Wadapter plate 2 125-1545

Xﬁ ber washer 1 540-9431

YM5 x 10mm phillips screw 1 520-9250

ZM8 x 50mm socket pin screw 16 521-1013

(

)

(

)

(

)

(

)

extension column

Fiber washer

cross support

nylock nut

Product specificaties

Merk:	Peerless-AV
Categorie:	Flat panel steun
Model:	DST940-BTB
Kleur van het product:	Zwart
Gewicht:	29000 g
Breedte:	621 mm
Diepte:	284 mm
Hoogte:	437 mm
Gewicht verpakking:	33000 g
Breedte verpakking:	1753 mm
Diepte verpakking:	178 mm
Hoogte verpakking:	317.5 mm
Montage gereedschap:	Ja
Montagewijze:	Plafond
Maximale gewichtscapaciteit:	34 kg
Aantal displays ondersteund:	2
Bereik kantelhoek:	0 - 20 °
Maximale schermgrootte:	46 "
Code geharmoniseerd systeem (HS):	85299097
Minimale schermgrootte:	37 "
Geschikt voor computerscherm:	Ja
