Pagina 1/1
Fig. 6
Instruction Manual
Boom Tilter
StopLock
WingLoc
StopLock
Reversible Seat Cup
Gyro-Lock Tilter
Reversible Cymbal Washers
Knurled Post for Cowbells, etc.
Congratulations on your purchase!
To get optimum performance of your CH-1030B Cymbal Holder,
please read this Instruction Manual before playing.
Test the stability of the Holder before using. If
necessary, readjust the length of the boom, the
direction of the boom until the Holder is sufficiently
stable.
CH-1030B
PEARL CYMBAL HOLDER
WingLoc
Pearl’s patented WingLoc's quick release design makes
attaching and removing cymbals quick and easy.
Reversible Seat Cup
The Seat Cup is reversible and can be set to Float, to
allow cymbals to move freely, when set in the position
shown in (Fig.5-A) or it can Lock, to prevents rattle in
recording situations, when set in the position shown in
(Fig.5-B).
Reversible Cymbal Washer
The CH-1030B Cymbal Holder is equipped with Reversible
Cymbal Washers with a Felt side and Foam side. With the
Foam side against the cymbal, a bright, clear sound with
long sustain is achieved. The Felt side gives a warmer and
softer sound. Mix and match the top and bottom Reversible
Cymbal Washers to find the sound you like best (Fig.6).
Float
Fig. 5-A
Lock
Fig. 5-B
To remove the WingLoc, pull the
wings apart and lift the WingLoc
straight up (Fig.1).
T o a t t a c h , k e e p t h e
wings open and place
the W ingLoc and t he
Upper Cymbal Washer
over the Cymbal Post as
shown (Fig.2).
To adjust, snap either
one of the wings upward
as shown in Fig.3 and
rotate the WingLoc until
the desired tightness /
looseness of the cymbal
is achieved. Snap the
o t h e r w i n g u p w a r d
(Fig.4) to lock the Wing-
Loc in place.
Fig. 1
Fig. 2
Fig. 3 Fig. 4
Upper
Cymbal Washer
Cymbal Post
NOTE
・Do not force the wings closed. If you feel resistance, rotate
the WingLoc slightly to align the threads and try closing the
wings again.
・Do not tighten the WingLoc when both wings are in the
locked position to prevent wear to the threads.
・Keep WingLocs in the locked position when transporting to
avoid breakage or loss.
http://www.pearldrum.com
Products and specifications are subject to change without notice.
Printed in China
-1502
Foam
Felt
Combination Example
CAUTION
