1

Thank you very much for purchasing our Patlite products.

●Request the installation and wiring be performed by a professional contractor if construction work is involved.

● Prior to installation, read this manual thoroughly before using this product to ensure correct use. In addition, please

store this manual for future reference when performing maintenance, repairs or inspections.

●

If there are any questions concerning this product, refer to the contact information at the end of this document and contact

your nearest PATLITE Sales Representative.

WebManual

WallMountBracket/CeilingMountBracket

RubberGasket/UpperBracket/NPTBracket

GA000146203

TYPE SZK / SZW / SZP

● Read this manual carefully prior to installation.

Notice to Customer

To the Contractor

(Top：Product Name Bottom：Model)

SZK-101

Wall Mount Bracket

SZK-102

Wall Mount Bracket

SZK-105

SZK-104

SZK-103

Wall Mount Bracket

Wall Mount Bracket Cover

Wall Mount Bracket Cover

Ceiling Mount Bracket

SZW-101

SZP-103

NPT Bracket

Rubber Gasket

Rubber Gasket

SZW-103

SZW-102

ApplicableModels

1. Be sure to read the instruction manual included with the Applicable Models in addition to this model.

RotatingBeaconsSK , Multi-functionBeaconsSF , FlashingBeaconsSL

〈Note〉

This product is an optional part for use in combination with its Applicable Models.

SZP-101

Upper Bracket

SZP-102

NPT Bracket

SZP-104

NPT Bracket
