PANDUIT LABEL APPLICATOR SYSTEM

OPERATION MANUAL

Original Instructions

This manual contains instructions for the following:

PLA-100, PLA-H100, PLA-R, and PLA-S

Label Applicator System

WARNING

• TO REDUCE THE RISK OF INJURY,

USER MUST READ INSTRUCTION

MANUAL

Email:

Ga-techsupport@panduit.com

EU Website:

www.panduit.com/emea

EU Email:

emeatoolservicecenter@panduit.com

www.panduit.com

For Technical Support

USA & Canada: 1-866-871-4571

Latin America: +52-33-3777-6000

Europe: +31-546-580-452

Asia Pacific Region: 65-6379-6700

Japan: 81-3-6863-6060

© Panduit Corp. 2020
PLA-100, PLA-H100


Rev. 02                                                                                                                              1 / 2021
Page 1 of 34
Contents
1: INTRODUCTION ................................................................................................................... 3
2: SYSTEM SPECIFICATIONS .................................................................................................. 3
2A: PLA-H100 Applicator Head .............................................................................................. 5
2B: PLA-100 Benchtop Label Applicator ................................................................................. 5
2C: PLA-T100X2400 Pressure Sensitive Adhesive Tether ..................................................... 6
2D: PLA-R Label Rewinder ..................................................................................................... 6
2E: PLA-S English Unit Retractable Scale .............................................................................. 6
2F: PLA-SP Empty Media Spool ............................................................................................. 7
2G: RMEH1BL-PLA 1” Ribbon Label media match 520ft long for TDP43ME .......................... 7
2H: RHEH1BL-PLA 1” Ribbon with typical length for TDP43HE Printer .................................. 7
3: GENERAL POWER TOOL SAFETY WARNINGS .................................................................. 8
  3A: Work Area Safety .................................................................................................. 8
  3B: Electrical Safety ..................................................................................................... 8
  3C: Personal Safety ..................................................................................................... 9
  3D: Stationary Tool Use and Care ............................................................................... 9
  3E: Service and Warranty ...........................................................................................10
4: SAFETY PRACTICES ADDENDUM .....................................................................................10
  4A: General Safety Practices ......................................................................................10
  4B: Electrical Safety Practices ....................................................................................10
  4C: Operational Safety Practices ................................................................................10
5: FCC EMISSION CLASSIFICATIONS ....................................................................................11
6: TECHNICAL SPECIFICATIONS ...........................................................................................11
6A: Electrical Specifications ...................................................................................................11
6B: Noise Emission ...............................................................................................................12
6C: Environmental .................................................................................................................12
7: PACKING LIST .....................................................................................................................12
7A: PLA-100 ..........................................................................................................................12
7B: PLA-H100 .......................................................................................................................13
