Operating Instructions

Functional Manual

FULL HD LCD Display For business use

Model No. TH-49LFV8U

49-inch model

TH-49LFV8W

49-inch model

TH-55LFV8U

55-inch model

TH-55LFV8W

55-inch model

English

* The instructions in this manual apply to all models irrespective of the

suffixes to the model number.

U: for US, Canada and Mexico

W: for EU, CIS, South East Asia and Middle East Asia

Please read these instructions before operating your

Display and retain them for future reference.

English

DPQP1189ZA

Dear Panasonic Customer

Welcome to the Panasonic customer family. We

hope that you will have many years of service and

enjoyment from your new LCD Display.

To obtain maximum benefit from your Display,

please read these Instructions before making

any adjustments, and hold on to them for future

reference.

Keep your purchase receipt as well, and record the

model and serial numbers of your set in the space

provided on the rear cover.

Visit our Panasonic Web Site http://panasonic.

com

Table of Contents

Before use

Pictures and images of screens in this manual are for

illustration only and may be different from the actual

physical device.

Important Safety Instructions ..........................3

FCC STATEMENT .............................................. 4

Important Safety Notice ...................................5

Safety Precautions ...........................................6

Precautions for use .......................................... 8

Accessories ....................................................10

Accessories Supply ·········································· 10

Remote Control Batteries ·································· 11

VESA Mounting ............................................... 11

Cautions when moving ..................................12

Kensington security lock ...............................12

Identifying Controls ........................................13

Main unit ························································ 13

Interface ························································ 14

Remote Control ··············································· 15

Connections ....................................................17

AC cord connection ········································· 17

Cable fixing ···················································· 17

Before connecting ············································ 18

PC Input Terminals connection ··························· 18

VIDEO IN connection ········································ 19

COMPONENT connection ································· 19

AUDIO OUT connection ···································· 20

Speaker connection ·········································· 20

HDMI1, HDMI2 connection ································ 20

DVI-D input / DVI-I output connection ··················· 21

DisplayPort input/output connection ····················· 22

SERIAL terminal connection ······························· 23

IR terminal connection ······································ 24

USB terminal connection ··································· 24

Connecting Multiple Displays in a Daisy-chain

configuration ··················································· 25

Basic controls .................................................26

Watch the Connected Video Source ···················· 26

Change Picture Format ····································· 26

Choose your Preferred Picture Settings ················ 26

Choose your Preferred Sound Settings················· 26

Play multimedia files from a USB device ··············· 26

Function controls ...........................................29

Picture ··························································· 29

Sound ··························································· 30

Tiling ····························································· 30

General Settings ·············································· 31

Network settings ·············································· 34

Using the Network Function ..........................35

The environment necessary for a computer connection

Example of network connection ·························· 35

For instructions on connection, consult r ·············· 35

Computer operation ·········································· 36

PJLink protocol ················································ 36

Early Warning Software ····································· 38

Multi Monitoring & Control Software ····················· 38

USB device compatibility...............................39

Input Mode ......................................................42

Troubleshooting ............................................. 44

Technical Specifications ................................ 46

Product specificaties

Merk:	Panasonic
Categorie:	Monitor
Model:	TH-49LFV8U
Kleur van het product:	Zwart
Gewicht:	22000 g
Breedte:	1077.7 mm
Diepte:	103.9 mm
Hoogte:	607.9 mm
Gewicht verpakking:	35000 g
Breedte verpakking:	1374 mm
Diepte verpakking:	373 mm
Hoogte verpakking:	901 mm
Gebruikershandleiding:	Ja
Beeldschermdiagonaal:	48.5 "
Resolutie:	1920 x 1080 Pixels
Touchscreen:	Nee
USB-poort:	Ja
Ondersteuning voor plaatsing:	Binnen
Ethernet LAN:	Ja
Kijkhoek, horizontaal:	178 °
Kijkhoek, verticaal:	178 °
Meegeleverde kabels:	AC, DisplayPort
Typische contrastverhouding:	1300:1
Helderheid:	450 cd/m²
Aantal HDMI-poorten:	2
Audio-ingang (L, R):	1
PC audio ingang:	Ja
DVI-poort:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	1
Ingebouwde luidsprekers:	Ja
Gemiddeld vermogen:	20 W
Aantal ingebouwde luidsprekers:	2
Stroomverbruik (in standby):	0.5 W
Aantal USB-aansluitingen:	1
Beeldscherm, aantal kleuren:	1.073 biljoen kleuren
HDCP:	Ja
Stroomverbruik (indien uit):	0 W
USB-versie:	2.0
HD type:	Full HD
Display technologie:	LED
Responstijd:	8 ms
Pixel pitch:	- mm
Levensduur paneel:	50000 uur
VESA-montage:	Ja
Paneelmontage-interface:	400 x 400 mm
Model:	Horizontaal/Verticaal
Bedoeld voor:	Universeel
Bedrijfsuren (uren/dagen):	24/7
DVI-D poorten:	1
Remote (IR) ingang:	1
Computersysteem:	Nee
Contrast ratio (dynamisch):	50000:1
Geïntegreerde TV Tuner:	Nee
Aantal DisplayPorts:	1
Ethernet LAN, data-overdrachtsnelheden:	10, 100 Mbit/s
Impedantie:	8 Ohm
Temperatuur bij opslag:	-20 - 60 °C
Soort paneel:	IPS
LED backlight-type:	Direct-LED
Luchtvochtigheid bij opslag:	5 - 95 procent
DVI-I poorten:	1
Remote (IR) uitgang:	1
Hoogte, in bedrijf:	0 - 2800 m
Hoogte bij opslag:	2800 - 9000 m
Afstandsbediening inbegrepen:	Ja
Productontwerp:	Videomuur
AC-ingangsspanning:	110 - 127 V
AC-ingangsfrequentie:	50 - 60 Hz
Stroomverbruik (typisch):	220 W
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	20 - 80 procent
Batterijen inbegrepen:	Ja
