and value in everything we make. To ensure you get the most out of your new patio speakers, please take a moment to read this manual before you get started.
Installing Speakers
These weather resistant patio speakers are manufactured to resist
a variety of weather condition. The most ideal place to install these
speakers is the undersides of most eaves and overhangs as they
provide the best protection.
Like all speakers, they sound the best when placed no more than
seven feet apart from each other, and slightly higher than ear level.
If the speakers are more than seven feet apart, toe them in toward
the center of the listening area.
These speakers are not waterproof and cannot be submerged under
water.
Placing Speakers
If your application requires the speaker to be mounted, please
follow these directions. Mount the
plastic knobs supplied. Never mount a speaker on a wall made
of unreinforced drywall or plasterboard. If you are unsure,
consult a professional contractor. (See Diagram 1)
Painting the grilles
The metal grilles may also be painted. Use very thin paint (5:1). It will
plugging up the holes with excess paint.
Mounting
To install the bracket on the speaker. Screw the bracket knobs into the
cabinet. Point the speaker toward the listening area. Once the direction
of the speaker has been determined tighten the bracket knobs securely.
(See Diagram 2)
Diagram 1
Screw
Bracket
Diagram 2
First remove the grille from the speaker then using spray paint lightly go
over the front of the grille and then go over the back of the grille.
Two coats may be nessesary for desired look.
Knob
Knob
x
x
Patio Speaker Installation Manual
Product specificaties
| Merk: | OSD Audio |
| Categorie: | Speaker |
| Model: | AP850 |
| Kleur van het product: | Zwart |
| Gewicht: | - g |
| Breedte: | 279.4 mm |
| Diepte: | 254 mm |
| Hoogte: | 386.08 mm |
| Gebruikershandleiding: | Ja |
| Connectiviteitstechnologie: | Bedraad |
| Snelstartgids: | Ja |
| Gemiddeld vermogen: | 200 W |
| Aanbevolen gebruik: | Universeel |
| Impedantie: | 8 Ohm |
| Geschikt voor buitengebruik: | Ja |
| Audio-uitgangskanalen: | 1.0 kanalen |
| Speaker plaatsing: | Floor, Tabletop/bookshelf, Wall-mountable |
| Aantal drivers: | 2 |
| Woofer: | Ja |
| Frequentiebereik: | 37 - 22000 Hz |
| Gevoeligheid: | 90 dB |
| Luidspreker soort: | 5-weg |
| Versterker: | Nee |
| Diameter woofer: | 8 " |
| Aantal woofer drivers: | 1 |
| Diameter hogetonenluidspreker: | 2 " |
| Aantal tweeter drivers: | 1 |
| Tweeter: | Ja |
| AirPlay: | Nee |
| Multi-Room Streaming (MRS)-ondersteuning: | Nee |
