Product data sheet
ORNO GROUP Sp. z o. o. All rights reserved.
Page 1 / 3
Update date: 2025-07-16 17:08:06
Industrial power supply for a DIN rail, 24VDC, 4A, 96W,
plastic housing
Marka: | Symbol: | Ean: Orno OR-PSU-1672 5908254848315
PRODUCT DESCRIPTION
The industrial power supply for a DIN rail is a modern and versatile device for increasing the efficiency and
safety of industrial installations in switchboards, switchgears or machines used in automation.
The unit provides a stable 24V DC output voltage with a maximum output current of 4A with up to 6A load
capability. The 12-48V AC output voltage range allows to adjust its operation to different system
requirements. An output power of 96W and a precise voltage stabilization guarantee efficient and reliable
Product data sheet
ORNO GROUP Sp. z o. o. All rights reserved.
Page 2 / 3
Update date: 2025-07-16 17:08:06
power supply to the connected devices.
The unit is equipped with an advanced short-circuit, surge and current protection, increasing operational
safety and securing both the power supply and the connected devices. It is Class II rated, therefore it meets
the high safety standards required in industry.
It is intended for heavy-duty use. Its design facilitates air to flow freely, preventing overheating and
supporting long-term, stable operation. Resistance to low and high temperatures further enhances the
device's reliability in a variety of environments.
Activation of the power supply is indicated by a LED diode. In addition, it is equipped with a potential-free
output, which allows more advanced control over the unit. Screws ensure permanent and secure wire
connection. DIN rail mounting. Suitable for indoor use (IP20).
The power supply has compact dimensions (55x92x100 mm) to save space in switchboards and switchgears.
The plastic housing and high-quality components ensure a long service life.
The device complies with standards: EN 55032 (CISPR32), EN 61204-3, EN 61000-3-2-3, EAC TP TC 020,
CNS1348, UL508, EN 62368-1, EAC TP TC 004, CNS14336-1 AS/NZS 62368.1.
TECHNICAL DATA
General information:
Voltage type of supply voltage:
AC
1st secondary output voltage at DC [V]:
24
Max. output current 1 [A]:
4
Max. output current 2 [A]:
6
Max. Overload [%]:
150
Max. Overcurrent [V]:
180
Secondary voltage adjustable [V]:
12-48
Short-circuit-proof:
Tak
Rated supply voltage at AC 50 Hz [V]:
85-264
Rated supply voltage at AC 60 Hz [V]:
85-264
Output voltage stabilized:
Tak
Line Regulation:
±1%
Product data sheet
ORNO GROUP Sp. z o. o. All rights reserved.
Page 3 / 3
Update date: 2025-07-16 17:08:06
Power output [W]:
96
Efficiency:
0.86
Stabilized:
Tak
Type of electric connection:
Połączenie Śrubowe
Rail mounting possible:
Tak
Wall mounting possible:
Nie
Direct mounting possible:
Nie
Width [mm]:
55
Height [mm]:
92
Depth [mm]:
100
Degree of protection (IP):
IP20
Operating Temperature:
-20 - +60
Storage Temp:
-40 - +85
Storage Humidity(RH)::
10 - 95%
Working Humidity(RH): / wilgotność podczas pracy
(bez kondensacji):
20 - 95%
Compliance with standards:
EN 55032 (CISPR32), EN 61204-3, EN 61000-3-2-3, EAC
TP TC 020, CNS1348, UL508, EN 62368-1, EAC TP TC
004, CNS14336-1 AS/NZS 62368.1
