Pagina 1/13
WPS01 Reverse Parking Assist System
Keep this user guide for future reference. Always retain your proof of purchase
in case of warranty service.
www.oricom.com.au
Tutorial videos are available -oricom.com.au,
select your model and scroll down to FAQ's
Operating Instructions
Keep this user guide for future reference. Always retain your proof of purchase
in case of warranty service.
www.oricom.com.au
Tutorial videos are available -oricom.com.au,
select your model and scroll down to FAQ's
01
02
Contents
Important Note
Parking Assist System (PAS) assists drivers
when reversing or parking by sounding an
audible beep to warn the driver of surrounding
objects.
1. This system is for vehicles with 12~24V DC.
2. This system should be installed by a
professional auto electrician.
3. Route wiring hamess away from heat source
and electrical components.
4. lt is strongly recommended to check the
position of the sensors before installation.
5. Perform a functional test after installation.
6. The PAS is designed as a driver assistance
device, and should not be used as a substitute
for safe parking practices. The area into which
the vehicle is to be reversed must be
constantly visually monitored while parking.
Oricom international do not guarantee or
assume liability for collisions or damages while
reversing the vehicle.
Pack Inclusions
Sensor gasket (10°) x 4 Sensor gasket (5°) x 4
Note: 4° sensor cover already fitted to sensor.
※The above graphics are for reference only
Sensor wire x 4
Sensor x 4
Sensor bracket x 4
Speaker ECU
User manual
Cable ties
Important Note
2
Product Information
Key Features
Specifications
Speaker Overview
Voice Adjustment
Volume Adjustment
Self Test Instruction
Leaming function for cars with tow-bars or spare
wheels
3
3
3
3
4
4
5
6
Attention
Sensor maintenance
Typical Alert distances
7
7
8
Pack Inclusions
2
Installation tools
Sensor Installation
Buzzer Installation
Functional Test after Installation
Wiring Diagram
Troubleshooting
19
20
21
22
Express Warranty (Australia)
23
9
10
Sensor cover x 4
