WARNING: Risk of Fire or Electric Shock

• To avoid damage, falling, electric shock or re, do not modify the lamp or

replace accessories without conrming with the supplier rst.

• Only authorized, qualied personnel should install this xture and should

follow the owner’s manual. Any improper installation might cause failure,

electric shock, re or other injury, damage or hazard.

• Disconnect power before installation or any maintenance of the xture.

• Do not dismantle the xture without the supplier’s authorization.

• Do not touch the power supply when the xture is operating.

• The external flexible cable or cord of this xture cannot be replaced; if the

cord is damaged, the xture shall be destroyed.

• Terminal block not included. The electrical tting must be installed by a

licensed electrician.

• For use in environments where an accumulation of non-conductive dust

on the xture may be expected.

IMPORTANT: This product must be installed in accordance with the

applicable installation code by a person familiar with the construction and

operation of the product and the hazards involved.

LED UFO HIGH BAY

Models: 65-781, 65-782, 65-783, 65-784, 65-785, 65-786, 65-787, 65-788,

65-791, 65-792, 65-793, 65-794, 65-795, 65-796, 65-797, 65-798,

65-801, 65-802, 65-803, 65-804, 65-805, 65-806, 65-807, 65-808

INSTALLATION AND SAFETY INSTRUCTIONS

IMPORTANT: Read before installing xture. Retain for future reference.

SPECIFICATIONS

ModelCCT VoltsCRI

Operating

Temperature

65-7814000K

100-277V80

-40°C to +45°C

(-40°F to +113°F)

65-7825000K

65-7834000K

65-7845000K

65-7854000K

65-7865000K

65-7874000K

65-7885000K

65-7914000K

65-7925000K

65-7934000K

65-7945000K

ModelCCTVoltsCRI

Operating

Temperature

65-7954000K120-277V

80

-40°C to +45°C

(-40°F to +113°F)

65-7965000K120-277V

65-7974000K120-277V

65-7985000K120-277V

65-8014000K200-480V

65-8025000K200-480V

65-8034000K200-480V

65-8045000K200-480V

65-8054000K200-480V

65-8065000K200-480V

65-8074000K200-480V

65-8085000K200-480V

WIRING DIAGRAM & INSTRUCTIONS

The LED high bay light can be equipped with an

optional DC motion sensor (86/218). The sensor

needs to be set via remote (86/219). For standard

0-10V dimming applications, the dimming cable must

be cut free from the integrated DC sensor port.

65-781, 65-782, 65-783, 65-784,

65-791, 65-792, 65-793, 65-794,

65-801, 65-802, 65-803, 65-804

:

ø11 13/6" (300mm)

65-784, 65-785, 65-787, 65-788,

65-795, 65-796, 65-797, 65-798,

65-805, 65-806, 65-807, 65-808

:

ø14 3/16" (360mm)

A B: Motion Sensor
