Pagina 1/2
1
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
UndercounterUndercounter
Dish Machine StandDish Machine Stand
MODELS
495STAND24
495STAND24KIT
COMPATIBLE UNITS
495NOWFNH30V
495NOWFU3FDV
495NOWFNL30X
12/2024
Prior to Assembly and Installation
Inspect for damage. Verify that all correct parts are included
immediately upon receiving:
A (1) Frame
B (4) Stainless Steel Adjustable Feet
C (8) Stainless Steel Hex Screws
D (8) Stainless Steel Flat Washers
E (4) Spring Washers
Make sure the dishwasher is unplugged and fully drained prior to installing.
NOTE: Always install with a partner and practice proper lifting techniques to prevent injury. Installers will have to lay the dishwasher on its top
to install. Make sure this is done slowly, safely, and with control. Avoid dropping or damaging the dishwasher. To prevent scratching, do not place
directly on a hard surface.
Assembly Instructions
STEP 1
Place the frame (A) on its top with the bottom facing upwards.
For 495STAND24KIT, align the top of the second frame with the
bottom of the first and fasten together using the (4) included hex
screws (C) and flat washers (D).
A
C
D
STEP 2
Adjust each foot (B) to the desired height. Ensure the height of the nut
results in a level frame.
B
2
UndercounterUndercounter
Dish Machine StandDish Machine Stand
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
STEP 3
Install the four adjustable feet (B) to the frame (A) with a flat
washer (D).
A
B
D
STEP 4
Place the stand on its feet to ensure that it is stable and level.
Installation Instructions
1. Remove feet of the undercounter dishwasher.
2. Align holes of the frame with that of the dishwasher’s feet holes.
3. Using the stainless steel hex screws (C), spring washers (E), and flat washers (D), fasten the stand securely to the bottom of the dishwasher.
4. With a partner, place the dish machine upright on a level surface.
5. Before reconnecting utilities, verify that the machine is level and that the connections are tightened.
6. Reconnect and run your machine, inspecting for excess vibration or sources of concern.
