Pagina 1/3
N 90, iNtegrated raNgehood, 70 cm, Black
d76NPc1S0a
Z5135X1 Standard odor filter (replacement)
Z5135X3 Standard recirculation kit
Z51ITD1X1 Long Life recirculation kit external
Z51ITP0X0 Long Life odor filter (replacement)
Z51IXB1X6 Clean Air Plus odor filter (replacement)
Z51IXC1X6 Clean Air Plus recirc. kit external
Your undermount rangehood fits discreetly into your cabinet for
more spacious versatility in the home
√ Efficient Drive Motor – Quiet and energy-efficient motor for a
calmer kitchen.
√ Intensive Setting – A peak performance beats steam during
intense cooking with automatic revert.
√ Hidden Design: Seamlessly integrate your hood in a flush fitted
cupboard design.
√ LED Lighting – Clear illumination while you cook.
√ Dimmer Function: Easily dim the light according to your mood
with the touch of a finger.
Typology: ......................................................... Built-in/Built-under
Length electrical supply cord: .......................................... 150.0 cm
Required niche size for installation (HxWxD): ..................345mm x
676.0mm x 264mm mm
Minimum distance above an electric cooktop: ................... 600 mm
Minimum distance above a gas cooktop: ...........................650 mm
Net weight: ........................................................................ 11.1 kg
Type of control: .............................................................. Electronic
Number of power settings: .................. 3-stages + intensive setting
Maximum output air extraction: .......................................590 m³/h
Boost position output recirculating: .................................760 m³/h
Maximum output recirculating air: ................................... 560 m³/h
Boost position air extraction: ...........................................800 m³/h
Number of lights: .........................................................................2
Noise level: .......................................................... 61 dB(A) re 1pW
Diameter of air outlet: ..............................................120 / 150 mm
Grease filter material: .................................................... Washable
aluminium
EAN code: ............................................................4242004282662
Connection Rating: .............................................................. 172 W
Fuse protection: ........................................................................3 A
Voltage: .........................................................................220-240 V
Frequency: ......................................................................60; 50 Hz
Plug type: .......................................................................... AU plug
Installation typology: ...........................................................Built-in
1 /
N 90, iNtegrated raNgehood, 70 cm, Black
d76NPc1S0a
Design:
• For installation in a kitchen cabinet
• Flush-fitted installation for a seamless integration in wall cupboards.
• Suitable for ducted extraction and recirculation
• For recirculated extraction various recirculation kits are available as
optional accessories.
Features:
• 2 x 1 Watt LED lights with color temperature selectable from 2 fixed
values
• Softlight: the lighting elements switch on and off smoothly.
• Colour Temperature: 4000 K
• Light Intensity: 300 lux
• EfficientDrive: Efficient BLDC technology
• 2 metal grease filter(s).
Comfort Features:
• Electronic controls with low-lift push buttons
• Saturation indicator for grease filters
• Automatic after running (10 minutes)
• 3 power levels plus intensive setting
• Automatic reset from intensive to normal setting after 6 min
Cleaning Comfort:
• Metal grease filter dishwasher-safe
• Easy to clean smooth surfaces and materials.
Performance Exhaust:
• According to EN 61591 and EN/ IEC 60704-2-13 your appliance can
achieve the following values in exhaust mode: Speed 1:extraction
rate 255 m3/h; noise level 41 dB (A) re1pW Speed 2: extraction rate
385 m3/h; noise level 51 dB (A) re1pW Speed 3: extraction rate 590
m3/h; noise level61 dB (A) re1pW Intensive 1: extraction rate 800
m3/h; noise level69 dB (A) re1pW
Performance Recirculation:
• According to EN 61591 and EN/ IEC 60704-2-13 your appliance can
achieve the following values in recirculation mode with standard
recirculation kit (available as optional accessory):
• Speed 1: extraction rate180 m3/h; noise level 56 dB(A) re1pW
• Speed 2: extraction rate250 m3/h; noise level 62 dB(A) re1pW)
• Speed 3: extraction rate350 m3/h ; noise level 70 dB(A) re1pW)
• Intensive Speed 1: extraction rate440 m3/h; noise level 75 dB (A)
re1pW)
Technical Information:
• Power rating: 172 W
• Voltage: 220 - 240 V
• Expanded plastic free packaging
Planning and Installation Information:
• Appliance dimensions (HxWxD): 345 x 700 x 282 mm
• Dimensions recirculating (HxWxD): 345-345 x 700 x 282 mm
• Installation dimensions (HxWxD): 345 x 676 x 264 mm
• Please reference the built-in dimensions provided in the installation
drawings
• Electrical cable length 1.5 m
• Diameter pipe Ø 150 mm (Ø 120 mm enclosed)
• with one-way flap: prevents outside air from entering your kitchen
2 /
