Pagina 1/4
Rockman
®
X100
™
Analog
Tone Processor
The MXR Rockman X100 Analog Tone Processor
revives the signature sonic character of Tom Scholz’s
celebrated headphone amp and signal processor
in pedal form. Offering crystalline cleans, crunchy
harmonics, and shimmering modulation, the original
X100 unit defined the sound of arena rock. This
faithful, all-analog recreation features the same four
tonal presets, carefully calibrated compression for
a clear sound whether clean or distorted, the same
bucket-brigade chorusing as the original, both mono
and stereo modes, and optional external mode
switching for an enhanced user experience.
MX100
jimdunlop.com/mx100
MX100 | MXR
®
Rockman
®
X100
™
Analog Tone Processor 2
1 CTRL jack allows MODE function to be controlled with
an off-board switch such as the MXR Tap or MXR TRS
Split + Tap.
2 FOOTSWITCH toggles effect on/bypass
3 MODE button cycles through four different tone presets:
two differently equalized clean modes with high-power
sustain and two distinctively gritty dirty modes.
4 CLN2 mode: Default setting. Provides a clean, crystal clear
tone.
5 CLN1 mode: Mid-focused EQ curve. Tuned for a tight,
punchy sound.
2
External Controls
3
1
4
5
6
7
8 9
10
6 Edge mode: Moderate clipping. Very sensitive to INPUT
GAIN adjustments and cleans up nicely at low guitar
volume settings.
7 Distortion mode: High-energy overdrive and sustain
that makes for easy, fluid leads.
8 VOLUME slider adjusts overall output volume.
9 INPUT GAIN slider adjusts input gain level. Increase for
a more compressed sound.
10 CHORUS button adds chorus effect.
MX100 | MXR
®
Rockman
®
X100
™
Analog Tone Processor 3
The MXR
®
Rockman
®
X100 Analog Tone Processor
requires 9 volts and can be powered by a Dunlop
ECB003 9-volt adapter or an MXR
®
Brick
™
Series
power supply.
Power
ALTERNATE SETUP OPTIONS
The Rockman X100 Analog Tone Processor is
designed to enhance your tone through any setup.
But if you want a subtler high-end response, try
running the pedal into the return of your amp’s FX
loop or a full-range/flat-response speaker system.
INTERNAL MONO/STEREO OUTPUT
SWITCH
Remove bottom plate to access. This switch toggles
between mono mode (default) and stereo mode at the
OUTPUT jack.
MONO MODE: Entire signal goes to OUTPUT jack.
Use a standard instrument cable.
STEREO MODE: When using a TRS splitter cable,
the selected MODE preset will be split evenly to both
channels. If CHORUS effect is engaged, the effect
will be varied on the left and right channels for a more
spacious and dynamic effect. Note: If using a standard
(mono) instrument cable in stereo mode, the pedal
will work as if in mono mode but the signal will be cut
when pedal is bypassed.
Controls
