8495 Dalton Road, Mount Royal, Quebec, Canada. H4T 1V5

Tel: (514) 905-0588 Fax: (514) 905-0589

Toll Free (North America): (877) 689-5228

E-mail: [email protected] URL: www.muxlab.com

© MuxLab Inc.

A

94-000859-A SE-000859-

Specifications

Installation

1.

Specifications

Environment

2 years

500920 16-Port Rackmount Transceiver Chassis

500917 Wall Mount Transceiver Bracket Kit

500989 Univ. Power Supply 12VDC/1.25A LOCK US/UK/EU

Quad single-channel balanced analog audio and Dante audio.

Dante/Quad Channel Audio PoE Gateway (500765)

Quick Installation Guide

Identify theconnectors on the Dante/Quad Channel Audio PoE Gateway unit as indicated

on the product labels,seethe above front and rear product views for further details.

Overview

TheDante/QuadChannelAudioPoEGatewaypermitsnon-Dantecompatibleanalogaudio

equipmenttointerfacewithDantecompatibleprofessionalaudioequipment,andmaybe

managedbytheAudinateDanteControllersoftware.

TheunitallowsDualtwo-channelorQuadsingle-channelfullrange(20Hzto20KHz)balanced

analogaudiosignalstobetransmittedoverthenetworktoDantecompatibleprofessionalaudio

equipment.Dualtwo-channelorQuadsingle-channelbalancedanalogaudiosignalsmayalsobe

receivedfromDantecompatibleequipmentinthesamemanner.Theunitmaybeconnectedvia

Cat5e/6cableupto330ft(100m)fromanEthernetSwitch.

TheDante/QuadChannelAudioPoEGatewayincludesfoursingle-channelbalancedanalog

audio-inandfoursingle-channelbalancedanalogaudio-outports,viaphoenixconnectors.The

Quadsingle-channelbalancedanalogaudio-inportsmaybeconnectedtolinelevelbalanced

analogaudiosignalsortolinelevelbalancedmicrophones.TheQuadsingle-channelbalanced

analogaudio-outportsmaybeconnectedtobalancedanalogaudioamplifierssupportingline

levelinputs,suchastheMuxLab500217AudioZoneAmplifier100W,ortotwopairsof

poweredspeakersfordirectsoundoutput.

ThedevicesupportsPoE(PD)andmaybepoweredbyaPoE(PSE)EthernetSwitch.

TheIPAddresscanbechangefromDHCPtostatic.

Applications

InterfacingnetworkedDantedigitalaudioequipmentwith2CHanalogaudioequipmentin

professionalandcommercialaudioapplicationsoverlongdistances.

Devices

Connectors

Maximum Distance

Signal Protocol/Standard

Bandwidth

RJ45 Pin Configuration

Cables

Power Source

PoE

Power Consumption

Temperature

Dimensions

Weight

Compliance

Warranty

Order Information

Accesories

Analog audio equipment and Dante professional audio equipment.

Two (2) 6-pin phoenix connector, for Quad single-channel balanced analog audio-in.

Two (2) 6-pin phoenix connector, for Quad single-channel balanced analog audio-out.

One (1) RJ45S for Cat 5e/6 unshielded or shielded twisted pair, for Ethernet connection.

One (1) 2.1mm jack, for power.

1) Network connection: Use Cat5e/6 at 330ft (100m) from Ethernet Switch.

2) Balanced 2CH analog audio connection using a MuxLab 500028 Stereo HiFi

__Balun: Use Cat5e/6 at 3250ft (1km) from 500028 Stereo HiFi Balun.

3) Balanced and Unbalanced connections directly connected to analog audio

__equipment: See analog audio equipment for maximum distance specifications.

Note: When installed in an electrically noisy environment, an STP cable must be used. Also, cross-

connection reduces the effective distance depending on the grade of twisted cable used.

Dante

Analog: 20Hz to 20KHz, Network: TBD.

RJ45 Link

Pin 1 (R)Pin 2 (T)

Pin 3 (R)Pin 6 (T)

Pin 4 (R)Pin 5 (T)

Pin 7 (R)Pin 8 (T)

One (1) Cat 5e/6 or better twisted pair cables required.

Eight (8) Quad single-channel balanced audio cables with 3-pin phoenix connectors

(for audio-in and audio-out).

This device supports PoE (PD), an external power supply is not included. It is

intended to be powered via a PoE (PSE) Ethernet Switch. If required, an optional

power supply may be purchased separately.

IEEE 802.3af

4.5W

Operating: 0° to 40°CStorage: -20° to 85°C

Humidity: Up to 95% non-condensing

4.4” x 4.6” x 1.0” (111mm x 120mm x 25mm)

1.5lbs (0.7kg)

Regulatory: FCC, CE, RoHSFlammability: 94V0

500765 Dante/Quad Channel Audio PoE Gateway

Reverse Polarity Sensitive.

Use EIA/TIA 568A or 586B

straight-through wiring.

Note: Cables not included.
