Pagina 1/62
PRO Series
Motherboard
PRO B650-VC WIFI II
User Guide
2
Contents
Quick Start .......................................................................................................................4
Case stand-off notification ....................................................................................... 6
Avoid collision notification ....................................................................................... 6
Specifications ................................................................................................................17
Special Features ............................................................................................................21
Package Contents .........................................................................................................22
Back Panel Connectors ................................................................................................23
LAN Port LED Status Table ...................................................................................... 24
Audio Jacks Connection ......................................................................................... 24
Installing Antennas ................................................................................................. 26
Overview of Components ............................................................................................27
CPU Socket .............................................................................................................. 28
DIMM Slots ............................................................................................................... 29
PCI_E1~4: PCIe Expansion Slots ............................................................................. 30
SATA_1~4: SATA 6Gb/s Connectors ........................................................................ 31
M2_1~3: M.2 Slots (Key M) ...................................................................................... 32
JAUD1: Front Audio Connector .............................................................................. 33
JFP1, JFP2: Front Panel Connectors ...................................................................... 33
CPU_PWR1, ATX_PWR1: Power Connectors .......................................................... 34
JCI1: Chassis Intrusion Connector ......................................................................... 35
JUSB5: USB 3.2 Gen 1 Type-C Front Panel Connector .......................................... 36
JUSB3~4: USB 3.2 Gen 1 Connectors ..................................................................... 36
JUSB1~2: USB 2.0 Connectors ............................................................................... 37
JTPM1: TPM Module Connector ............................................................................. 37
JOC_FS1: Safe Boot Jumper .................................................................................. 38
CPU_FAN1
, PUMP_FAN1, SYS_FAN1~3
: Fan Connectors ..................................... 39
JBAT1: Clear CMOS (Reset BIOS) Jumper .............................................................. 40
JRGB1~2: RGB LED connectors .............................................................................. 41
JARGB_V2_1~2: A-RAINBOW V2 (ARGB Gen2) LED Connectors ............................ 42
Onboard LEDs................................................................................................................44
EZ Debug LED .......................................................................................................... 44
English
