MPG Series
Motherboard
MPG X870E CARBON WIFI
User Guide
2
Contents
Quick Start .......................................................................................................................4
Specifications ................................................................................................................17
Special Features ............................................................................................................22
Package Contents .........................................................................................................23
Back Panel Connectors ................................................................................................24
2.5Gbps LAN Port LED Status Table ....................................................................... 26
5Gbps LAN Port LED Status Table .......................................................................... 26
Audio Jacks Connection ......................................................................................... 27
Installing Antennas ................................................................................................. 29
Overview of Components ............................................................................................30
CPU Socket .............................................................................................................. 31
DDR5 DIMM Slots ..................................................................................................... 33
PCI_E1~3: PCIe Expansion Slots ............................................................................. 35
M2_1~4: M.2 Slots (Key M) ...................................................................................... 38
SATA_S1_S2, SATA_P3_P4: SATA 6Gb/s Connectors ............................................. 46
JAUD1: Front Audio Connector .............................................................................. 46
JFP1, JFP2: Front Panel Connectors ...................................................................... 47
CPU_PWR1~2, ATX_PWR1, PCIE_PWR1: Power Connectors ................................. 48
JCI1: Chassis Intrusion Connector ......................................................................... 49
POWER1, RESET1: Power Button, Reset Button .................................................... 49
JUSBC1: USB 20Gbps Type-C Front Panel Connectors ......................................... 50
JUSB1~2: USB 5Gbps Connectors .......................................................................... 50
JUSB3~4: USB 2.0 Connectors ............................................................................... 51
T_SEN1: Thermal Sensor Connector ..................................................................... 51
JOC_FS1: Safe Boot Jumper .................................................................................. 52
JBAT1: Clear CMOS (Reset BIOS) Jumper .............................................................. 52
CPU_FAN1, PUMP_SYS1, SYS_FAN1~5: Fan Connectors ....................................... 53
JRGB1: RGB LED connector .................................................................................... 54
JARGB_V2_1~3: A-RAINBOW V2 (ARGB Gen2) LED connectors ............................. 55
JAF_2: EZ Conn-Header V2 ..................................................................................... 57
