Pagina 1/182
1
<變數 1> Contents
Contents
Safety Information ........................................................................................... 2
Specifications ...................................................................................................3
Package contents.............................................................................................6
Rear I/O Panel ..................................................................................................7
LAN Port LED Status Table .................................................................................7
Overview of Components ................................................................................8
CPU Socket .........................................................................................................9
DIMM Slots ........................................................................................................10
PCI_E1~3: PCIe Expansion Slots ......................................................................10
JFP1, JFP2: Front Panel Connectors ...............................................................11
SATA1~4: SATA 6Gb/s Connectors....................................................................11
ATX_PWR1, CPU_PWR1: Power Connectors....................................................12
M2_1: M.2 Slot (Key M) .....................................................................................12
JUSB1~2: USB 2.0 Connectors .........................................................................13
JUSB3~4: USB 3.1 Gen1 Connectors ................................................................13
CPU_FAN1, SYS_FAN1~2: Fan Connectors ......................................................14
JTPM1: TPM Module Connector .......................................................................15
JCI1: Chassis Intrusion Connector ...................................................................15
JAUD1: Front Audio Connector ......................................................................... 16
JCOM1: Serial Port Connector .........................................................................16
JRGB1, JRGB2: RGB LED Connectors ..............................................................16
JBAT1: Clear CMOS (Reset BIOS) Jumper .......................................................17
EZ Debug LED: Debug LED indicators ..............................................................17
BIOS Setup ..................................................................................................... 18
Entering BIOS Setup .........................................................................................18
Resetting BIOS ..................................................................................................19
Updating BIOS ...................................................................................................19
Software Description .....................................................................................21
Installing Windows
®
10 .....................................................................................21
Installing Drivers ..............................................................................................21
Installing Utilities ..............................................................................................22
Thank you for purchasing the MSI
®
B450M GAMING PLUS
motherboard. This User Guide gives information about
board layout, component overview, BIOS setup and software
installation.
2
Safety Information
Safety Information
y The components included in this package are prone to damage from electrostatic
discharge (ESD). Please adhere to the following instructions to ensure successful
computer assembly.
y Ensure that all components are securely connected. Loose connections may cause
the computer to not recognize a component or fail to start.
y Hold the motherboard by the edges to avoid touching sensitive components.
y It is recommended to wear an electrostatic discharge (ESD) wrist strap when
handling the motherboard to prevent electrostatic damage. If an ESD wrist strap is
not available, discharge yourself of static electricity by touching another metal object
before handling the motherboard.
y Store the motherboard in an electrostatic shielding container or on an anti-static
pad whenever the motherboard is not installed.
y Before turning on the computer, ensure that there are no loose screws or metal
components on the motherboard or anywhere within the computer case.
y Do not boot the computer before installation is completed. This could cause
permanent damage to the components as well as injury to the user.
y If you need help during any installation step, please consult a certified computer
technician.
y Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing any computer component.
y Keep this user guide for future reference.
y Keep this motherboard away from humidity.
y Make sure that your electrical outlet provides the same voltage as is indicated on
the PSU, before connecting the PSU to the electrical outlet.
y Place the power cord such a way that people can not step on it. Do not place
anything over the power cord.
y All cautions and warnings on the motherboard should be noted.
y If any of the following situations arises, get the motherboard checked by service
personnel:
Liquid has penetrated into the computer.
The motherboard has been exposed to moisture.
The motherboard does not work well or you can not get it work according to
user guide.
The motherboard has been dropped and damaged.
The motherboard has obvious sign of breakage.
y Do not leave this motherboard in an environment above 60°C (140°F), it may
damage the motherboard.
3
Safety Information Specifications
Specifications
CPU
Support AMD
®
Ryzen™ 1st and 2nd Generation/ Ryzen™ with
Radeon™ Vega Graphics Processors for Socket AM4
Chipset AMD
®
B450 chipset
Memory
y 2x DDR4 memory slots, support up to 32GB*
Supports 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)
Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz
(by A-XMP OC MODE)
y Dual channel memory architecture
y Supports ECC UDIMM memory (non-ECC mode)
y Support non-ECC UDIMM memory
* Please refer www.msi.com for more information on
compatible memory.
Expansion Slots
y 1x PCIe 3.0 x16 slot
Supports x16 speed with AMD
®
Ryzen™ 1st and 2nd
Generation processors
Supports p3-x8 speed with AMD
®
Ryzen™ with Radeon
Vega Graphics processors
y 2x PCIe 2.0 p3-x1 slots
Onboard
Graphics
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz*
y 1x HDMI™ 1.4 port, supports a maximum resolution of
4096x2160 @30Hz, 2560x1600 @60Hz*
* Only support when using AMD
®
Ryzen™ with Radeon Vega
Graphics Processors
* Maximum shared memory of 2048 MB
Storage
AMD
®
B450 Chipset
y 4x SATA 6Gb/s ports
Supports RAID 0, RAID1 and RAID 10
y 1x M.2 slot (Key M)
Supports PCIe 3.0 p3-x4 and SATA 6Gb/s 2242/ 2260 /2280
storage devices
Audio
y Realtek
®
ALC887 Codec
y 7.1-Channel High Definition Audio
Continued on next page


Product specificaties

Merk: MSI
Categorie: Lens
Model: B450M GAMING PLUS
Breedte: 244 mm
Diepte: 210 mm
Gebruikershandleiding: Ja
Ethernet LAN: Ja
Meegeleverde kabels: SATA
Aantal USB 2.0-poorten: 6
Aantal HDMI-poorten: 1
Aantal Ethernet LAN (RJ-45)-poorten: 1
HDMI versie: 1.4
DVI-D poorten: 1
Ondersteunt Windows: Windows 10, Windows 7
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: 4
Processor socket: Socket AM4
Processorfabrikant: AMD
Maximum intern geheugen: 32 GB
Audio-uitgangskanalen: 7.1 kanalen
Snelle installatiehandleiding: Ja
ECC: Ja
Ethernet interface type: Gigabit Ethernet
Chipset moederbord: AMD B450
Geheugen slots type: DIMM
Audiochip: Realtek ALC887
Meegeleverde drivers: Ja
Type koeling: Passief
Geheugen kanaal: Dubbelkanaals
PCI Express x16 (Gen 3.x) slots: 1
Component voor: PC
LAN controller: Realtek RTL8111H
Maximum geheugen grafische adapter: 2048 MB
Aantal SATA III connectors: 4
Non-ECC: Ja
Compatibele processors: AMD Athlon, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Ondersteunde geheugen types: DDR4-SDRAM
Max. aantal SMP-processoren: 1
PCI Express x1 (Gen 2.x) slots: 2
Moederbord chipset familie: AMD
Moederbord form factor: micro ATX
Aantal geheugenslots: 2
Supported memory clock speeds: 1866,2133,2400,2667,2800,2933,3000,3066,3200,3466 MHz
BIOS type: UEFI
ATX Power connector (24-pin): Ja
Voorpaneel-connector: Ja
USB 2.0 aansluitingen: 2
Aansluiting voor audiopaneel aan voorzijde: Ja
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen: 2
TPM connector: Ja
Chassis intrusion aansluiting: Ja
EPS power connector (8-pin): Ja
Clear CMOS jumper: Ja
Aantal M.2 (M) slots: 1
Aantal montagegaten: 6
12V vermogen-connector: Ja
RGB LED-aansluitrail: Ja
Serial port headers: 1
