PRODUCT SAFETY AND RF EXPOSURE COMPLIANCE

ATTENTION!

This radio is restricted to occupational use only to satisfy FCC RF energy exposure

requirements. Before using this product, read the RF energy awareness information and operating

instructions in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola

Publication part number 6881095C98) to ensure compliance with RF energy exposure limits.

For a list of Motorola-approved antennas, batteries, and other accessories, visit the following web

site which lists approved accessories: http://www.motorola.com/governmentandenterprise

Mag One™

by Motorola is registered in the U.S. Patent and Trademark Office.

All other products and service names are the property of their own respective owners.

© Motorola, Inc. 2005, 2006, 2007

1301 E. Algonquin Rd.,

Schaumburg, IL 60196-1078, U.S.A.

Printed in China. 02/07. All Rights Reserved.

Before using this product, read the operating instructions for safe usage

contained in the Product Safety and RF Exposure booklet enclosed with your

radio.

*6881098C61*

6881098C61-D

Attaching and Removingthe Antenna

To Attach Antenna

To Remove Antenna

1.Fasten the antenna to the radio by placing

the threadedend of the antennainto the

Antenna Connector.

2.Rotatethe antenna clockwiseuntil tight.

1.

Turn the antenna in a counter-clockwise

direction until it disengages fromthe

radio.

Threaded End

of Antenna

Antenna

Connector

Attaching and Removing the Battery

To Attach Battery

ToRemove Battery

1.Align and fit the battery tongue into the

grooveof the chassis ofthe radio.

2.Secure thelatch atthe bottom of the

radio.

1.Unlatch the battery clasp atthe bottom of

the radio.

2.Gently lift the hiltof the battery nearestto

the battery latch away from the housing.

3.Slide battery downwards toremove.

Attaching and Removing the BeltClip

To Attach Belt Clip

ToRemove Belt Clip

1.Align mounting rails ofthe radio with the

grooves of the belt clip.

2.Slide the belt clip downwards until it clicks

into place.

1.Lift the release tab.

2.Slide the belt clip upwards.

Release Tab

Charging your Radio

1.Turn offyour radio and the A/C power

supply to yourcharger (ifthey are on).

2.Place your radio in the charger pocket.

3.Turn on the charger’sA/C power supply.

4.While charging your radio,the charger’s

LED shows asteady red light. The radio

should be charged at least 16 hours initially

before decreasing charging time to 12

hours.

5.Turn off thecharger’s A/C power supply,

and remove the radio from the charger

pocket.

6.For more details, refertoyour Tri-Chem

Charger User Guide (6871916T01).

Charger Pocket
