Pagina 1/2
Thank you for choosing MOMAN product. Please read this manual carefully
before use and follow all instructions mentioned herein.
User Manual
MOMAN
C1X
Microphone
Slow Flashes
Fast Flashes
Keeps On
Fast ashes twice, is
o and repeats
Power is lower than 10%.
/
/
It stays green when charging and is o
after fully charged.
Power on
System pairing
System paired
Low cut function is on.
Power Indicator (Green) Pairing Indicator (Blue)
TX Transmitter x2
3.5mm TRS Camera Cable x1
RX Receiver x1
External Lav Mic (With Wind Mu)
x2
Mic Windshield
x2
3-in-1 Charging Cable x1
3.5mm TRRS Phone Cable x1
Carrying Bag x1Eject Pin x1
Package List
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product
to prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if
any malfunctions happened.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
Caring For Your MOMAN Product
Product Introduction
Product Introduction
TX Transmitter
RX Receiver
Indicator
1.External Mic Input
2.USB-C Port
3.Power
4.Reset (Help with Eject Pin)
5.Low Cut
6.Pairing
7.Built-in Mic
8.Pocket Clip
9.Pairing Indicator
10.Power Indicator
1.USB-C Port
2.Power (Mono/Stereo
Switch)
3.Reset (Help with Eject Pin)
4.Channel A Gain Control
5.Channel B Gain Control
6.3.5mm Audio Output
7.3.5mm Monitoring Jack
8.Pocket Clip
9.Pairing Indicator
10.Power Indicator
1.Power Button
Long press the power button for 2 seconds to turn on/o the system.
Short press the power button on the RX for Mono/Stereo switch.
2.Pairing
The system will pair automatically after power on. If you need manual pairing,
long press the channel A gain control and channel B gain control on the RX,
and the pairing button on the TX, the system will start to pair.
3.Connection
The receiver outputs audio signals to recording devices with a 3.5mm TRRS
Phone Cable or a 3.5mm TRS Camera Cable. Please use the corresponding
cable based on your device.
4.Installation
Attach the transmitter or the external mic to the speaker’s clothing. Install the
receiver to the camera’s hot shoe via the pocket clip.
(Note: When using the external mic, please insert it into the mic input properly.)
Adjust the recording level of inbuilt mics for Canon Camera
(Take EOS 5D Mark Ⅳ for example)
Adjust the recording level of inbuilt mics for Panasonic Camera
(Take LUMIX GH5 for example)
Wireless Transmission
RF Frequency Band
Working Distance
Latency
Mounting
Audio Input
Audio Input Level
RF Output Power
Power Requirements
Battery Type
Battery Charging Time
Battery Life
Dimensions
Material
Weight
Wireless Transmission
RF Frequency Band
Approximate RF Sensitivity
Working Distance
Latency
Mounting
Sound Field
Polar Pattern
Frequency Range
Sensitivity
Maximum SPL
Digital 2.4GHz
2400-2483.5MHz
164ft/50m (LOS area), 98ft/30m (NLOS area)
12.5ms
Pocket Clip
1/8" / 3.5 mm TRS Mic Input
1V (0dBV)
＜10mW
3.3V-4.7V
Built-in Lithium Battery
1.5H
8H
52X42X16mm
Plastic
35g
Digital 2.4GHz
2400-2483.5MHz
-81dBm
164ft/50m (LOS area), 98ft/30m (NLOS area)
12.5ms
Pocket Clip
Mono
Omnidirectional
50Hz-20KHz
-40dB (±3 dB, re 1V/Pa at 1KHz)
135dB SPL (at 1KHz)
TX Transmitter
RX Receiver
Microphone
Unit 25 Basepoint Business Centre, Aviation Park, West Christchurch, United
Kingdom BH23 6NX
www.momanmic.com www.momanx.com www.momanx.co.uk
@MomanGlobal
https://moman.co/youtube
Moman (UK) Limited
Specications
Number of Audio Channels
Audio Output
Gain
Audio Output Level
Power Requirements
Battery Type
Battery Charging Time
Battery Life
Dimensions
Material
Weight
2
1/8” / 3.5 mm TRS Mic Output
1/8” / 3.5 mm TRS Headphone Output
0-4 Level (0 to 8dB)
Line Out: 1V, Monitoring: 25-30mW
3.3V-4.7V
Built-in Lithium Battery, 400mAh
1.5H
8H
52X42X16mm
Plastic
35g
Setting The Recording Level Correctly
5.Gain Control
The initial value of the gain is the microphone's original volume. Each press of
the gain control button increases the gain by one level, fourth level at most.
When the gain is at max level, press once and return to initial value.
6.Charging
Please fully charge the TX and RX via the USB-C port and the charging cable
before use.
Camera devices generally have poor-quality, noisy preamps. In order to get the
cleanest signals possible, it is highly recommended that you set the recording
level on your camera quite low, 1/2 or 1/3 of it.
The product provides variable gain control, allowing you to tailor your levels to
just about environment and recording device.
Adjust the recording level of inbuilt mics for SONY Camera
(Take A7S Ⅱ for example)
