Pagina 1/10
NOTE!
This guide is only valid for the 2MP IR Vandal Turret. For more inform-installing and connecting
ation on the camera, please refer to the other documents (see ). Further Reading, p. 9
Important Installation Notes
n
This camera must be installed by qualified personnel and the installation should conform to
all local codes.
n
This product must not be used in locations exposed to the dangers of explosion.
n
Do not use this product in a dusty environment.
n
Protect this product from moisture or water entering the housing.
n
Install this product as outlined in this document. A faulty installation can damage the
product!
n
Do not replace batteries of the camera. If a battery is replaced by an incorrect type, the bat-
tery can explode.
n
This equipment is not suitable for use in locations where children are likely to be present.
n
External power supplies must comply with the Limited Power Source (LPS) requirements and
share the same power specifications with the camera.
n
When using a ClassI adapter, the power cord shall be connected to a socket-outlet with
proper ground connection.
n
To comply with the requirements of EN 50130-4 regarding the power supply of alarm systems
for 24/7 operation, it is highly recommended to use an uninterruptible power supply (UPS) for
backing up the power supply of this product.
V1.07_1/29/2024, Order Code: Mx-VT1A-2-IR
Quick Installation
MOBOTIX MOVE 2MP IR Vandal Turret
Mx-VT1A-2-IR
©2024 MOBOTIX AG
Quick Installation 2MP IR Vandal Turret
NOTE! To ensure that the unit is not affected by vibration, twisting, etc. after adjusting the camera,
properly tighten all mounting screws.
Package Contents
Check the package for the items listed below.
2MP IR Vandal Turret
3 x Plastic anchors
3 x self tapping screws
1 x Cable entry cover
1 x Water proof cover
1 x Security Torx Wrench (T 1 0) * 1
1 x Drilling template
Disassembling the Camera
1.
Loosen the screw on the top cover using the T10 Torx wrench.①
2.
Remove the top cover .②
3.
Carefully remove the camera lens module from the bottom camera case .③ ④
2 / 10
Inserting the SD Card
CAUTION! Always power down the camera before performing the following steps!
1.
Remove the SDcard cover from the camera lens module by loosening the screws with ① ①
the T10 Torx wrench.
2. Insert the SD card into the corresponding slot.
3. Reattach the SD card cover.
Quick Installation 2MP IR Vandal Turret
3 / 10
