Pagina 1/116

Network Video Recorder

User Manual

V3.06

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to

avoid danger or property loss. The precaution measures are divided into “Warnings”

and “Cautions”

Warnings: Serious injury or death may be caused if any of these warnings is

neglected.

Cautions: Injury or equipment damage may be caused if any of these cautions are

neglected.

Warnings: Please follow these safeguards to

prevent injury or death.

Cautions: Please follow these safeguards to

prevent potential injury or material damage.

Warnings



This installation must be conducted by a qualified service person and should

strictly comply with the electrical safety regulations of the local region



To avoid risk of fire and electric shock, do keep the product away from rain

and moisture



Do not touch components such as heat sinks, power regulators, and

processors, which may be hot



Source with DC 12V or PoE



Please make sure the plug is firmly inserted into the power socket



When the product is installed on a wall or ceiling, the device should be firmly

fixed



If the product does not work properly, please contact your dealer. Never

attempt to disassemble the camera by yourself

Cautions



Make sure that the power supply voltage is correct before using the camera



Do not store or install the device in extremely hot or cold temperatures,

dusty or damp locations, and do not expose it to high electromagnetic

radiation



Only use components and parts recommended by manufacturer



Do not drop the camera or subject it to physical shock



To prevent heat accumulation, do not block air circulation around the

camera



Laser beams may damage image sensors. The surface of image sensors

Product specificaties

Merk:	Milesight
Categorie:	Videorecorder
Model:	MS-N7032UH
Kleur van het product:	Zwart
Gewicht:	4100 g
Breedte:	440 mm
Diepte:	320 mm
Hoogte:	66.8 mm
LED-indicatoren:	Ja
Aan/uitschakelaar:	Ja
Ondersteund audioformaat:	G.711
Ondersteunde videoformaten:	H.264, H.265
Maximum resolutie:	3840 x 2160 Pixels
Maximale beeldsnelheid:	30 fps
Resolutie bij opnamesnelheid:	1280x720@30fps, 1920x1080@30fps
Aantal USB 2.0-poorten:	2
Aantal Ethernet LAN (RJ-45)-poorten:	2
Ethernet LAN, data-overdrachtsnelheden:	10, 100 Mbit/s
RS-232:	Ja
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	1
Ondersteunde netwerkprotocollen:	IPv4, HTTP, NTP, SMTP, PPPoE, DDNS
Rack-montage:	Ja
Totale geïnstalleerde opslagcapaciteit:	0 GB
Opname modes:	Event, Manual, Schedule
HDD capaciteit:	0 GB
HDD interface:	SATA
Power over Ethernet (PoE):	Nee
PTZ control:	Ja
RAID support:	Ja
HDD omvang:	3.5 "
Maximum aantal HDD's per behuizing:	4
Maximale opslagcapaciteit:	40 TB
VGA (D-Sub) uitgang ports:	1
Soorten RAID:	0, 1,5, 10
Rackcapaciteit:	1.5U
Videoingangkanalen:	32 kanalen
Alarmingangkanalen:	16
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Stroomverbruik (typisch):	15 W
Bedrijfstemperatuur (T-T):	-10 - 55 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
Audio RCA-ingangen:	1
RS-485 ports:	1
Backup-functie:	Ja
Snap shot:	Ja
HDMI-uitgang:	Ja
Alarmuitgangkanalen:	4
Gegevensdoorvoersnelheid:	320 Mbit/s
Audio RCA-uitgangen:	1
