PWR-LINE PRO

PWR-LINE PRO

The PWR-LINE PRO allows Ethernet-like connectivity between supported devices over regular electrical power lines. When plugged into the same

electrical circuit, the device will establish Ethernet connectivity by using the HomePlug AV 2 standard. The device supports 802.1q. PWR-LINE PRO does

not require any system software or configuration, it's ready to use.

Connecting

Plug one PWR-LINE PRO device into a power socket.

Connect to one of the LAN ports of your MikroTik router to the PWR-LINE PRO Ethernet port.

Plug another PWR-LINE PRO unit (or any other compatible device) somewhere in the same electrical circuit.

Use the sync button to connect the devices and your local network will automatically be extended. Please see the PWR connection button (sync)

section on how to pair additional PWR-LINE PRO devices.

PWR-LINE PRO supports PoE out from Ethernet port to power another Mikrotik device, this can be activated with a switch, please see LED lights

section.and PoE switch

Mounting

PWR-LINE PRO can be mounted on the wall using four provided screws:

To access mounting points, remove a center screw, that is holding top cover, using PH2 screwdriver.

Mark four points for screw holes in the desired place on the wall for PWR-LINE PRO.

Drill using a 5 mm drill bit for dowel holes and insert them by slight tapping if necessary.

Mount PWR-LINE PRO and close top cover, center screw tightening force 0.5 – 0.7 Nm, attach provided 3M sticker to cover center screw.

Powering
