Pagina 1/6

CRS-series

8 port device series models:

CRS109-8G-1S-2HnD-IN

CRS212-1G-10S-1S+IN

The CRS is a highly configurable switch, powered by RouterOS. Several models are available in the 8 Gigabit port

series:

CloudRouterSwitch 109-8G-1S-2HnD-IN

CloudRouterSwitch 112-8G-4S-IN

CloudRouterSwitch 210-8G-2S+IN

CloudRouterSwitch 212-1G-10S-1S+IN

First Use

Mount unit or place on the flat surface, please see paragraph for instructions.Mounting

Choose your powering solution, please see the section for possibilities.Powering

The Initial connection has to be done via the Ethernet cable, using the MikroTik Winbox utility.

Use Winbox to connect to the default IP address of 192.168.88.1 from any port, with the username admin and no password, the device is set up

as a switch. (or, for some models, check user and wireless passwords on the sticker)

Update the device by clicking the "Check for updates" button to v6.46 or the latest RouterOS software to ensure the best performance and

stability. The device needs to have an active internet connection.

To manually update the device, go to our download pagehttps://mikrotik.com/download

Choose your architecture (MIPSBE) and download the latest packages from any channel to your PC.

Open Winbox and upload packages in the Files menu.

Reboot the device.

Updating software will ensure the latest security fixes and regulations set by local law.

Choose your Country.

Set up your password to secure the device.

Powering

The devices accept power in the following ways:

direct-input power jack: 8-56V (24V 0.8A PSU included),

passive PoE input: 8-56V (injector included).

Except for CRS212-1G-10S-1+IN, which only accepts 8-30V direct input, with no PoE input support

Extension slots and ports

Except for CRS212: Eight (8) 10/100/1000 (Gigabit) Ethernet ports (Auto MDI/X).

For CRS109: One SFP cage, compatible with 1.25G SFP modules, Built-in 802.11b/g/n 2GHz wireless

access point.

For CRS112: Four SFP cages, compatible with 1.25G SFP modules.

Beoordeel deze handleiding

4.2/5 (9 Beoordelingen)

Product specificaties

Merk:	Mikrotik
Categorie:	Niet gecategoriseerd
Model:	CRS109-8G-1S-2HnD-IN
Kleur van het product:	Wit
Breedte:	200 mm
Diepte:	145 mm
Hoogte:	45 mm
Stroom:	0.8 A
Frequentie van processor:	600 MHz
Processormodel:	Qualcomm Atheros AR9344
Ethernet LAN:	Ja
Meegeleverde kabels:	USB
Inclusief AC-adapter:	Ja
Aantal Ethernet LAN (RJ-45)-poorten:	8
Vermogensverbruik (max):	13 W
DC voltage input:	24 V
Intern geheugen:	128 MB
Type processor:	Ja
Ethernet LAN, data-overdrachtsnelheden:	10,100,1000 Mbit/s
Bekabelingstechnologie:	10/100/1000Base-T(X)
Netwerkstandaard:	IEEE 802.3af, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Spanning:	57 V
Flash memory:	128 MB
Power over Ethernet (PoE):	Ja
Switch type:	Managed
Aantal basis-switching RJ-45 Ethernet-poorten:	8
Console port:	RJ-45
Netstekker:	DC-in ingang
Switch-laag:	L3
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF:	1
Wifi:	Ja
Bedrijfstemperatuur (T-T):	-35 - 65 °C
