UMT 70 S

Windscreen, anthraciteOrder-No. 202407

Order-No. 600018

Microphone holder, blackOrder-No. 202306

blackOrder-No. 600001

Elastic suspension, satin nickelOrder-No. 202318

Elastic suspension, black mattOrder-No. 202319

Elastic suspension, modified,anthraciteOrder-No. 600004

Power supplyOrder-No. 202101

Connection cableOrder-No. 202212

Popscreen, black

Clamp,

W 76

PO 70

MH 75

MKV 9

EA 21

EA 21

N 200

C 70

AT 8410 a

Accessories,optional

MICROTECHGEFELL

FÜRSTUDIO-UNDMESSTECHNIK

KONDENSATORMIKROFONE

SEIT 1928

Transformerless Condenser Microphone

with switchable polar pattern

TheUMT70Scondensermicrophone,equippedwithourreliablelarge

diaphragmcapsule,featuresoutstandingperformance,highsensitivity,and

improved signal-to-noise ratio.

TheUMT70Sguaranteesparticularlycleanandcolourlesssound

reproduction.Itiswellsuitedforinstrumentalandvocalsoloistsinradioand

television broadcasting and any other kind of accurate production.

Thepressuregradienttransducerisadualcapacitordesignthatusesa

singlebrassbackplateandtwolarge-diametergold-platedplastic

diaphragms.Varyingthepolarizationvoltageappliedtothediaphragms

resultsinthreedirectionalcharacteristics:omni,cardioidandfigure8.Aring

at the bottom of the microphone's head grille is used to select the pattern.

Theomni-directionalpatternshowsaslight2dBriseinthevicinityof

10,5kHzwhilethebassresponseisperfectlyflat.Thecardioidandfigure8

patternsexhibitasmoothpresenceboostrisingtoabout4dBinthe7kHz

range.Thisresponse,coupledwithaslightroll-offatlowfrequencies,is

responsible for the legendary 'presence' of this microphone.

Thedirectionofmaximumsensitivityisperpendiculartothemicrophone's

axis (side addressed).

Thenewlydevelopedtransformerlesscircuitdesignsubstitutestheprevious

transformerforasymmetricaloutputstageyieldingasuperbtransient

responsecombinedwithahighRFIrejection.Thecircuittechnologyalso

achievesawiderdynamicrangebyloweringtheself-noisefloorand

increasing the headroom for loud signals.

A10dBattenuatorhasbeeninstalledtoreducethesensitivityofthemicro-

phonewhenplacednearveryloudsoundsources.Asensitivityreductionfor

lowfrequenciescanbeutilizedtosuppresstheproximityeffectwhenclose-

miking with the cardioid or figure 8 patterns.

Themicrophoneisequippedwithastandard3-pinXLRconnectorfittingtoa

microphone cable, e.g. C 70.

TheoperationvoltagefortheUMT70Sisprovidedby48Vphantompower-

ing according to the international standards DIN 45596 and IEC 268-15.

The microphone is available in a satin nickel or a black matt finish.

Delivery

MicrophoneUMT 70 S in wooden case L x B x H 275 x 90 x 70 mm

satin nickelOrder-No. 211130

black mattOrder-No. 211131

MICROTECH GEFELL GMBH GEORGNEUMANNPLATZ D-07926 GEFELL TEL. ++49 (0)36649 / 882-0 FAX ++49 (36649 / 882 11--0)

INTERNET http://www.microtechgefell.dee-mail [email protected]
