PIC32CX-BZ2

PIC32CX-BZ2 MCHPRT3 User Guide

Introduction

This user guide provides detailed information about using the Microchip Radio Test 3 tool (MCHPRT3) with the

Microchip PIC32CX-BZ2. The MCHPRT3 enables the user to evaluate and demonstrate the RF performance,

calibration and functionalities of the PIC32CX-BZ2.

Note: In this user guide, the MCHPRT3 tool with the PIC32 WBZ451 Curiosity Board is only shown as an example.

The MCHPRT3 is intended for development purposes. Any production test must use either a third-party production

tool or users must develop their own production tool based on the DLL release.

Features

• DLL Version – DLL Information and Firmware Support Version

• COM PORT – COM Port Information and Configuration

• Baud Rate – 115200 (default value)

• RF Bluetooth

– Bluetooth Low Energy RF Parameter Configuration and Information

• RF ZB – Zigbee RF Parameter Configuration and Information

• MAC Address Information and Configuration

• IB File – Read or Save Information Block (IB) File

• Calibration Information and Configuration

• GPIO Information and Configuration

For more details, refer to 4. Getting Started.

and its subsidiaries

User Guide

DS50003379A-page 1
