Ultra-Precision Differential CML and LVPECL
Line Driver/Receiver w/Internal Termination
SY58600/601/602U Evaluation Board
September 2004M9999-092904
[email protected] or (408) 955-1690
General Description
The SY58600U, SY58601U and SY58602U
evaluation boards are designed for convenient set-up
and quick evaluation of the respective devices. They
allow the user to evaluate the part over the full
voltage-range of the parts without requiring any
modifications to the board.
The evaluation board standard configuration is AC-
coupled for direct interface to a 50 compatible
oscilloscope without split supplies. For applications
that require a DC-coupled configuration, step-by-step
instructions for modifying the board are included.
All data sheets and support documentation can be
found at Micrel’s web site at www.micrel.com.
.
Features
•SY58600U CML outputs
•SY58601U and SY58602U LVPECL outputs
•Single +2.5V or +3.3V power supply
•AC-coupled configuration for ease-of-use
•I/O interface includes on-board termination
•Fully assembled and tested
•Reconfigurable for DC-coupled operation
Related Documentation
•SY58600U Ultra-Precision Differential 400mV
CML Line Driver/Receiver with Internal
Termination Data Sheet
•SY58601U Ultra-Precision Differential 800mV
LVPECL Line Driver/Receiver with Internal
Termination Data Sheet
•SY58602U Ultra-Precision Differential 400mV
LVPECL Line Driver/Receiver with Internal
Termination Data Sheet
____________________________________________________________________________________
Evaluation Board
SY58600U AC-Coupled Evaluation Board
SY58601U/602U AC-Coupled Evaluation Board
