© 2015-2019 Microchip Technology Inc.DS60001344E-page 22-1

Section 22. 12-bit High-Speed Successive Approximation

Register (SAR) Analog-to-Digital Converter (ADC)

This section of the manual contains the following major topics:

22.1Introduction..................................................................................................................22-2

22.2Control Registers.........................................................................................................22-6

22.3ADC Operation...........................................................................................................22-61

22.4ADC Module Configuration........................................................................................22-65

22.5Additional ADC Functions..........................................................................................22-85

22.6Interrupts..................................................................................................................22-108

22.7Operation During Power-Saving Modes..................................................................22-114

22.8Effects of Reset........................................................................................................22-116

22.9Transfer Function.....................................................................................................22-116

22.10ADC Sampling Requirements..................................................................................22-117

22.11Connection Considerations......................................................................................22-117

22.12Related Application Notes........................................................................................22-118

22.13Revision History.......................................................................................................22-119
