© 2013-2015 Microchip Technology Inc.DS60001192B-page 50-1
Section 50. CPU for Devices with MIPS32
®
microAptiv™
and M-Class Cores
This section of the manual contains the following topics:
50.1Introduction..............................................................................................................50-2
50.2Architecture Overview.............................................................................................50-4
50.3PIC32 CPU Details..................................................................................................50-8
50.4Special Considerations When Writing to CP0 Registers.......................................50-13
50.5MIPS32 Architecture..............................................................................................50-14
50.6CPU Bus................................................................................................................50-15
50.7Internal System Busses.........................................................................................50-15
50.8Set/Clear/Invert......................................................................................................50-16
50.9ALU Status Bits......................................................................................................50-16
50.10Interrupt and Exception Mechanism......................................................................50-17
50.11Programming Model..............................................................................................50-17
50.12Floating Point Unit (FPU).......................................................................................50-24
50.13Coprocessor 0 (CP0) Registers.............................................................................50-42
50.14Coprocessor 1 (CP1) Registers...........................................................................50-121
50.15microMIPS Execution..........................................................................................50-132
50.16MCU ASE Extension...........................................................................................50-132
50.17MIPS DSP ASE Extension..................................................................................50-133
50.18Memory Model (MCU only)..................................................................................50-133
50.19Memory Management (MPU only).......................................................................50-135
50.20L1 Caches (MPU only)........................................................................................50-141
50.21CPU Instructions..................................................................................................50-145
50.22MIPS DSP ASE Instructions................................................................................50-151
50.23CPU Initialization.................................................................................................50-153
50.24Effects of a Reset................................................................................................50-154
50.25Related Application Notes...................................................................................50-155
50.26Revision History...................................................................................................50-156
